GATES

Gates 5206 Timing Belt

SKU: 5206
Your selected vehicle
Out of stock
Out of Stock
£34.60 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

CITROËN
BX (XB-_)
Description Cylinder Capacity Horse Power Year
19 GTi 16V 1905 CCM 147 HP 03/1988 - 02/1993
PEUGEOT
309 Mk II (3C, 3A)
Description Cylinder Capacity Horse Power Year
1.9 GTI 16V 1905 CCM 147 HP 10/1990 - 12/1993
1.9 GTI 16V 1905 CCM 158 HP 08/1989 - 07/1990
405   (15B)
Description Cylinder Capacity Horse Power Year
1.9 Sport MI-16 1905 CCM 158 HP 07/1987 - 11/1992
1.9 Sport MI-16 1905 CCM 147 HP 06/1987 - 07/1992
1.9 SPort MI-16 4x4 1905 CCM 147 HP 06/1987 - 07/1992

The Gates 5206 Timing Belt is a replacement belt-drive component that helps transmit drive between the relevant engine pulleys while maintaining the specified belt path. Its catalogue specification records Polychloroprene (Neoprene) belt material, 133 teeth, 25.4 mm width, and 1,267 mm length. Match the reference, belt profile or pulley dimensions, tooth data, driven units and engine application before fitting; observe the specified tensioning and timing procedure.

Function : Timing Belt
Article number of the recommended special tool : STT-1
Belt Material : Polychloroprene (Neoprene)
Number of Teeth : 133
Width [mm] : 25.4
Tooth Pitch [mm] : 9.525
Length [mm] : 1,267
Driven Units : Camshaft
  • Vendor GATES
  • SKU 5206
  • Barcode 5412571006339
  • CITROËN : 0816.40 081640 91540557 91541318
  • PEUGEOT : 0816.40 081640
  • DANA : PMTB118
  • APEC : AWB1055
  • APEC : BMC2024
  • APEC : MCY141
  • APEC : SHU469
  • BLUE PRINT : ADS75341
  • BLUE PRINT : ADS75352
  • BORG & BECK : BBW1919
  • BOSCH : 0 204 123 563
  • BOSCH : F 026 003 563
  • BREMBO : A 12 B91
  • BREMBO : M 85 035
  • DELPHI : LH6265
  • DELPHI : LM40251
  • DELPHI : LS1305
  • DELPHI : LW90169
  • FEBI BILSTEIN : 05206
  • FTE : 9220048
  • GATES : AV17X850HD
  • GATES : AWS2445
  • HELLA : 8AM 355 502-411
  • LEMFÖRDER : 18577 01
  • NAPA : NMC1032
  • NAPA : PWB1055
  • Schaeffler FAG : 713 6782 30
  • SKF : VKBA 769
  • SKF : VKBA 9067 CL
  • SKF : VKBA 9076 CL
  • SKF : VKBA 960
  • TRW : BWD361
  • TRW : PMH177
  • GATES : 859515206
