Gates 5245 Timing Belt - 1
Gates 5245 Timing Belt video
Gates 5245 Timing Belt - 1
Gates 5245 Timing Belt video
GATES

Gates 5245 Timing Belt

SKU: 5245
Your selected vehicle
Only 1 left
Low inventory - Hurry! — Order by 17:00 for same-day dispatch
£38.51 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

AUDI
80 B4 Avant (8C5)
Description Cylinder Capacity Horse Power Year
2.3 E 2309 CCM 133 HP 07/1992 - 01/1996
80 B4 Saloon (8C2)
Description Cylinder Capacity Horse Power Year
2.3 E 2309 CCM 133 HP 09/1991 - 12/1994
90 B3 (893, 894, 8A2)
Description Cylinder Capacity Horse Power Year
2.0 1994 CCM 115 HP 07/1988 - 09/1991
2.3 E 2309 CCM 136 HP 04/1987 - 07/1991
2.3 E 2309 CCM 133 HP 04/1987 - 09/1991
2.3 E quattro 2309 CCM 136 HP 04/1987 - 07/1991
2.3 E quattro 2309 CCM 133 HP 04/1987 - 09/1991
2.2 E 2226 CCM 136 HP 04/1987 - 07/1991
2.2 E quattro 2226 CCM 136 HP 04/1987 - 09/1991
100 C3 Avant (445, 446)
Description Cylinder Capacity Horse Power Year
2.0 E Cat 1994 CCM 115 HP 01/1988 - 11/1990
2.2 2226 CCM 137 HP 08/1984 - 12/1988
2.2 Turbo 2226 CCM 165 HP 08/1986 - 11/1990
2.3 2309 CCM 136 HP 08/1986 - 11/1990
2.3 2309 CCM 133 HP 03/1990 - 11/1990
100 C3 Saloon (443, 444)
Description Cylinder Capacity Horse Power Year
2.0 Cat 1994 CCM 115 HP 01/1988 - 11/1990
2.2 2226 CCM 137 HP 08/1984 - 12/1988
2.2 Turbo 2226 CCM 165 HP 08/1986 - 11/1990
2.3 E 2309 CCM 136 HP 10/1986 - 11/1990
2.3 E 2309 CCM 133 HP 01/1990 - 11/1990
200 C3 Saloon (447, 448)
Description Cylinder Capacity Horse Power Year
2.2 Turbo 2226 CCM 165 HP 08/1985 - 09/1991
2.2 Turbo quattro 2226 CCM 165 HP 01/1985 - 12/1991
2.2 Turbo quattro 2226 CCM 200 HP 02/1988 - 11/1990
2.2 Turbo 2226 CCM 190 HP 02/1988 - 12/1990
2.2 Turbo 2226 CCM 200 HP 02/1988 - 12/1990
200 C3 Avant (447, 448)
Description Cylinder Capacity Horse Power Year
2.2 Turbo quattro 2226 CCM 165 HP 09/1983 - 12/1990
2.2 Turbo quattro 2226 CCM 200 HP 02/1988 - 12/1991
2.2 Turbo 2226 CCM 165 HP 08/1985 - 09/1991
COUPE B2 (81, 855, 856)
Description Cylinder Capacity Horse Power Year
2.3 quattro 2309 CCM 133 HP 01/1987 - 12/1987
COUPE B3 (89, 8B3)
Description Cylinder Capacity Horse Power Year
2.3 2309 CCM 136 HP 10/1988 - 07/1994
2.3 2309 CCM 133 HP 03/1990 - 12/1996
2.3 quattro 2309 CCM 136 HP 11/1988 - 12/1992
2.3 quattro 2309 CCM 134 HP 05/1990 - 12/1996
QUATTRO (85)
Description Cylinder Capacity Horse Power Year
2.1 Turbo 2144 CCM 200 HP 07/1980 - 07/1987
2.2 Turbo 2226 CCM 200 HP 08/1987 - 07/1989
2.1 Turbo quattro 2144 CCM 162 HP 02/1982 - 07/1989

The Gates 5245 Timing Belt is a replacement belt-drive component that helps transmit drive between the relevant engine pulleys while maintaining the specified belt path. Its catalogue specification records Polychloroprene (Neoprene) belt material, 142 teeth, 19 mm width, and 1,136 mm length. Match the reference, belt profile or pulley dimensions, tooth data, driven units and engine application before fitting; observe the specified tensioning and timing procedure.

Function : Timing Belt
Article number of the recommended special tool : STT-1
Belt Material : Polychloroprene (Neoprene)
Number of Teeth : 142
Width [mm] : 19
Tooth Pitch [mm] : 8
Length [mm] : 1,136
Construction Year to : 11.1994
Driven Units : Camshaft
Vehicle Identification Number (VIN) from : 8C-N-000 001
Vehicle Identification Number (VIN) to : 8C-N-300 000
  • Vendor GATES
  • SKU 5245
  • Barcode 5412571007367
  • AUDI : 074 109 119
  • DANA : PMTB160
  • APEC : SHU144
  • BLUE PRINT : ADN14435
  • BORG & BECK : BBS6254
  • BOSCH : 0 242 240 715
  • BOSCH : 1 987 949 056
  • BREMBO : M 59 035
  • CORTECO : 80001351
  • DELPHI : LH6630
  • DELPHI : LM50013
  • DELPHI : LS1203
  • DENSO : VKH22
  • FEBI BILSTEIN : 101806
  • FEBI BILSTEIN : 16921
  • FEBI BILSTEIN : 17654
  • LEMFÖRDER : 14611 01
  • MONROE : MK205
  • TRW : BWB135
  • TRW : GCH169
  • TRW : PMF169
  • WAI : M5-245A
  • GATES : 859515245
