GATES

Gates 5306 Timing Belt

SKU: 5306
Your selected vehicle
Only 2 left
Low inventory - Hurry! — Order by 17:00 for same-day dispatch
£48.77 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

BEDFORD
BRAVA
Description Cylinder Capacity Horse Power Year
2.5 D 2499 CCM 76 HP 02/1990 - 07/1990
2.5 D 4WD 2499 CCM 76 HP 02/1990 - 07/1990
ISUZU
CAMPO (KB)
Description Cylinder Capacity Horse Power Year
2.5 D (KB27) 2499 CCM 75 HP 01/1983 - 12/1990
2.5 D 4WD (KBD47) 2499 CCM 75 HP 01/1983 - 12/1990
MU (_U_)
Description Cylinder Capacity Horse Power Year
3.1 TD 4x4 (UCS69) 3059 CCM 120 HP 08/1993 - 05/1998
TROOPER II (UB)
Description Cylinder Capacity Horse Power Year
3.1 TD 3059 CCM 114 HP 08/1991 - 07/1998
TROOPER II Open Off-Road Vehicle (UB)
Description Cylinder Capacity Horse Power Year
3.1 TD 3059 CCM 114 HP 08/1991 - 07/1998
TROOPER/BIGHORN I (UBS)
Description Cylinder Capacity Horse Power Year
2.8 TD (UBS55) 2771 CCM 97 HP 10/1987 - 12/1991
2.8 TD (UBS55) 2771 CCM 106 HP 10/1988 - 12/1991
2.8 TD 2771 CCM 101 HP 10/1987 - 12/1991
OPEL
CAMPO (TF0, TF1)
Description Cylinder Capacity Horse Power Year
2.5 D 4x4 (TFS54) 2499 CCM 76 HP 08/1991 - 06/1994
2.5 TD (TFR54) 2499 CCM 76 HP 07/1994 - 06/2001
2.5 TD 4x4 (TFS54) 2499 CCM 76 HP 07/1994 - 06/2001
FRONTERA A (U92)
Description Cylinder Capacity Horse Power Year
2.8 TD (5BMWL4, 5BSUD2) 2771 CCM 113 HP 03/1995 - 08/1998
MONTEREY A (M92)
Description Cylinder Capacity Horse Power Year
3.1 TD (UBS69D, UBS69G) 3059 CCM 114 HP 09/1991 - 07/1998
VAUXHALL
BRAVA Pickup (TF0, TF1)
Description Cylinder Capacity Horse Power Year
2.5 TD 4x4 (TFS54) 2499 CCM 76 HP 06/1990 - 06/1994
2.5 TD (TFR54) 2499 CCM 76 HP 08/1991 - 06/1994
2.5 TD (TFR54) 2499 CCM 76 HP 07/1994 - 12/2002
2.5 TD 4x4 (TFS54) 2499 CCM 76 HP 07/1994 - 12/2002
FRONTERA Mk I (A) (U92)
Description Cylinder Capacity Horse Power Year
2.8 TD 2771 CCM 113 HP 01/1995 - 12/1996
FRONTERA Mk I (A) Sport (U92)
Description Cylinder Capacity Horse Power Year
2.8 TD 2771 CCM 113 HP 01/1995 - 12/1996
MONTEREY (M92)
Description Cylinder Capacity Horse Power Year
3.1 TD 3059 CCM 114 HP 09/1991 - 07/1998

The Gates 5306 Timing Belt is a replacement belt-drive component that helps transmit drive between the relevant engine pulleys while maintaining the specified belt path. Its catalogue specification records Fiberglass tensile cord material, Polychloroprene (Neoprene) belt material, black colour, and 119 teeth. Match the reference, belt profile or pulley dimensions, tooth data, driven units and engine application before fitting; observe the specified tensioning and timing procedure.

Function : Timing Belt
Tensile Cord Material : Fiberglass
Belt Material : Polychloroprene (Neoprene)
Colour : black
Number of Teeth : 119
Width [mm] : 32
Tooth Pitch [mm] : 9.525
Length [mm] : 1,133
Driven Units : Camshaft
  • Vendor GATES
  • SKU 5306
  • Barcode 5412571008395
  • APEC : BCY1177
  • BLUE PRINT : ADK84678
  • BLUE PRINT : ADZ97301
  • BLUE PRINT : ADZ97506
  • BORG & BECK : BBW1138
  • BORG & BECK : BEM4251
  • BOSCH : 0 204 123 405
  • BOSCH : 1 987 482 138
  • BOSCH : 1 987 948 707
  • BOSCH : F 026 003 405
  • BREMBO : A 12 229
  • BREMBO : M 86 004
  • DELPHI : LM80242
  • DELPHI : LW60532
  • DENSO : IW20
  • DENSO : IW20TT
  • FEBI BILSTEIN : 109430
  • FEBI BILSTEIN : 49628
  • FIRST LINE : FEM4251
  • FTE : 9210087
  • FTE : 9220243
  • LEMFÖRDER : 16150 01
  • NGK : 2212
  • NGK : 3903
  • NGK : 4233
  • SKF : VKMT 99004
  • TRW : BWD188
  • TRW : GCH2626
  • TRW : PMK662
  • WAI : 15027N
  • GATES : 859515306
