KYB RA1397 Suspension Spring - 1
KYB RA1397 Suspension Spring - 2
KYB RA1397 Suspension Spring - 1
KYB RA1397 Suspension Spring - 2
KYB

KYB RA1397 Coil Spring

5.0/5 60 AutoMotoPart customer reviews Verified reviews across our products & service
SKU: RA1397

Check product compatibility

Enter your registration or select your vehicle to check this product fits.

Only 4 left
Low inventory - Hurry! — Orders placed by 17:00 are usually dispatched the same working day
£66.75 inc. VAT
Pay in 3 interest-free payments with Klarna
Free UK mainland standard delivery 14-day returns

Need help choosing the right part? Call 01472 869 066

AUDI
A4 B9 (8W2, 8WC)
Description Cylinder Capacity Horse Power Year
1.4 TFSI 1395 CCM 150 HP 08/2015 - 11/2019
2.0 TFSI 1984 CCM 190 HP From 05/2015
2.0 TFSI 1984 CCM 252 HP 05/2015 - 11/2019
2.0 TFSI quattro 1984 CCM 252 HP From 05/2015
2.0 TDI 1968 CCM 190 HP From 05/2015
2.0 TDI 1968 CCM 150 HP 05/2015 - 11/2019
2.0 TDI 1968 CCM 136 HP 05/2015 - 11/2019
2.0 TFSI 1984 CCM 249 HP 11/2015 - 11/2019
2.0 TFSI quattro 1984 CCM 249 HP 11/2015 - 11/2019
2.0 TDI 1968 CCM 122 HP 05/2016 - 11/2019
A4 B9 Avant (8W5, 8WD)
Description Cylinder Capacity Horse Power Year
2.0 TFSI 1984 CCM 190 HP From 08/2015
2.0 TFSI quattro 1984 CCM 252 HP 08/2015 - 10/2019
2.0 TDI 1968 CCM 190 HP 08/2015 - 09/2018
2.0 TDI 1968 CCM 150 HP 08/2015 - 09/2018
2.0 TFSI quattro 1984 CCM 249 HP 11/2015 - 10/2019
2.0 TDI 1968 CCM 136 HP 08/2015 - 10/2019
1.4 TFSI 1395 CCM 150 HP 02/2016 - 10/2019
2.0 TDI 1968 CCM 122 HP 04/2016 - 09/2018
2.0 TFSI 1984 CCM 252 HP 05/2016 - 10/2019
2.0 TFSI 1984 CCM 249 HP 05/2016 - 10/2019
A5 (F53, F5P)
Description Cylinder Capacity Horse Power Year
2.0 TDI 1968 CCM 190 HP From 07/2016
2.0 TFSI 1984 CCM 252 HP 11/2016 - 02/2020
2.0 TFSI 1984 CCM 190 HP From 09/2016
1.4 TFSI 1395 CCM 150 HP 11/2016 - 02/2020
2.0 TDI 1968 CCM 150 HP 05/2017 - 02/2020
40 TFSI Mild Hybrid 1984 CCM 190 HP From 05/2017
A5 Sportback (F5A, F5F)
Description Cylinder Capacity Horse Power Year
2.0 TFSI 1984 CCM 252 HP 11/2016 - 02/2020
2.0 TDI 1968 CCM 190 HP From 09/2016
1.4 TFSI 1395 CCM 150 HP 01/2017 - 02/2020
2.0 TFSI 1984 CCM 190 HP From 01/2017
2.0 TDI 1968 CCM 150 HP 01/2017 - 02/2020

The KYB RA1397 Coil Spring is a replacement suspension spring that supports vehicle load and works with the damper to control suspension movement. Its catalogue specification records front axle fitting position, coil Spring spring design, 12.5 mm thickness 1, and 121.7 mm outer diameter. It is listed in the suspension Spring product category. Confirm the reference, spring design, dimensions, axle position and vehicle application before fitting; springs should normally be renewed in axle pairs and installed with suitable spring-compression equipment.

Function : Suspension Spring
Fitting Position : Front Axle
Spring Design : Coil Spring
Weight [kg] : 1.47
Thickness 1 [mm] : 12.5
Outer Diameter [mm] : 121.7
Length [mm] : 283
  • Vendor KYB
  • SKU RA1397
  • Barcode 4549762313943
  • AUDI : 8W0411105HG 8W0411105FM 8W0411105FN 8W0411105HF
  • BLUE PRINT : ADN18350
  • BORG & BECK : BWK1420
  • FEBI BILSTEIN : 173046
  • FIRST LINE : FBK1420
  • KILEN : 10268
  • MONROE : SP4485
