KYB RA1503 Suspension Spring - 1
KYB RA1503 Suspension Spring - 2
KYB RA1503 Suspension Spring - 1
KYB RA1503 Suspension Spring - 2
KYB

KYB RA1503 Coil Spring

5.0/5 65 reviews
SKU: RA1503

Check product compatibility

Enter your registration or select your vehicle to check this product fits.

Only 3 left
Low inventory - Hurry! — Orders placed by 17:00 are usually dispatched the same working day
£68.89 inc. VAT

Pay in 3 interest-free payments with Klarna

Available at checkout. Subject to eligibility.

Free standard delivery to UK mainland

Delivery estimate confirmed at checkout. Delivery details
Pay securely with
  • Visa
  • Mastercard
  • Apple Pay
  • PayPal
  • Klarna
  • Google Pay

Need help with fitment? 01472 869 066

LAND ROVER
90 I (LDV)
Description Cylinder Capacity Horse Power Year
2.3 4x4 2286 CCM 71 HP 01/1984 - 08/1987
2.5 D 4x4 2495 CCM 69 HP 09/1985 - 08/1990
2.5 TD 4x4 2495 CCM 86 HP 09/1986 - 08/1990
110/127 (LDH)
Description Cylinder Capacity Horse Power Year
2.3 D 4x4 2286 CCM 63 HP 06/1984 - 08/1987
3.5 4x4 3528 CCM 136 HP 01/1985 - 07/1990
DEFENDER Station Wagon (L316, L315)
Description Cylinder Capacity Horse Power Year
2.5 TDI 4x4 (L316) 2495 CCM 113 HP 08/1990 - 12/1998
3.9 V8 4x4 (L316) 3947 CCM 185 HP 11/1998 - 02/2016
2.2 Td4 4x4 (L316) 2198 CCM 122 HP 08/2011 - 02/2016
2.5 4x4 2495 CCM 83 HP 09/1990 - 12/1994
3.5 4x4 3528 CCM 117 HP 09/1990 - 08/1993
2.4 Td4 4x4 (L316) 2402 CCM 122 HP 10/2006 - 02/2016
2.5 D 4x4 (L316) 2495 CCM 69 HP 09/1990 - 07/1994
2.2 Td4 4x4 (L316) 2198 CCM 150 HP 02/2015 - 02/2016
3.5 4x4 3528 CCM 136 HP 09/1990 - 07/1994
2.4 Td4 4x4 2402 CCM 140 HP 07/2007 - 02/2016
DEFENDER Cabrio (L316)
Description Cylinder Capacity Horse Power Year
2.5 TDI 4x4 (L316) 2495 CCM 113 HP 08/1990 - 11/1998
2.2 Td4 4x4 (L317) 2198 CCM 122 HP 08/2011 - 02/2016
2.5 Td5 4x4 (L316) 2495 CCM 122 HP 06/1998 - 02/2016
2.4 Td4 4x4 (L317) 2402 CCM 122 HP 05/2007 - 02/2016
2.5 D 4x4 (L316) 2495 CCM 69 HP 09/1990 - 07/1994
3.5 4x4 3528 CCM 117 HP 09/1990 - 08/1993
DEFENDER Pick Up (L316)
Description Cylinder Capacity Horse Power Year
2.2 Td4 4x4 (L317) 2198 CCM 122 HP 08/2011 - 02/2016
2.5 Td5 4x4 (L316) 2495 CCM 122 HP 06/1998 - 02/2016
2.4 Td4 4x4 (L317) 2402 CCM 122 HP 05/2007 - 02/2016
2.4 Td4 4x4 2402 CCM 140 HP 10/2009 - 05/2016

The KYB RA1503 Coil Spring is a replacement suspension spring that supports vehicle load and works with the damper to control suspension movement. Its catalogue specification records coil Spring spring design, 16 mm thickness 1, 151 mm outer diameter, and 390 mm length. It is listed in the suspension Spring product category. Confirm the reference, spring design, dimensions, axle position and vehicle application before fitting; springs should normally be renewed in axle pairs and installed with suitable spring-compression equipment.

Function : Suspension Spring
Spring Design : Coil Spring
Weight [kg] : 5.63
Thickness 1 [mm] : 16
Outer Diameter [mm] : 151
Length [mm] : 390
  • Vendor KYB
  • SKU RA1503
  • Barcode 4549762342387
  • LAND ROVER : NRC9448 RKB500280 NRC9449 RKB500290
  • APEC : AWB1106
  • BORG & BECK : BWK560
  • FIRST LINE : FBK560
  • KILEN : 29079
  • KILEN : 29081
  • MONROE : SP2959
  • MONROE : SP4952
  • NAPA : PWB1106
