KYB

KYB RH3344 Coil Spring

5.0/5 60 AutoMotoPart customer reviews Verified reviews across our products & service

SKU: RH3344

Check product compatibility

Enter your registration or select your vehicle to check this product fits.

Only 3 left

Low inventory - Hurry! — Orders placed by 17:00 are usually dispatched the same working day

£55.14 inc. VAT

Pay in 3 interest-free payments with Klarna

Free UK mainland standard delivery 14-day returns

Need help choosing the right part? Call 01472 869 066

TOYOTA

AURIS (_E15_)

Description	Cylinder Capacity	Horse Power	Year
1.6 (ZRE151_, ZRE151R)	1598 CCM	124 HP	03/2007 - 09/2012
1.4 (ZZE150_, ZZE150R)	1398 CCM	97 HP	03/2007 - 09/2012
1.33 Dual-VVTi (NRE150_, NRE150R)	1329 CCM	101 HP	05/2009 - 09/2012
1.6 (ZRE151_, ZRE151R)	1598 CCM	132 HP	05/2009 - 09/2012
1.33 Dual-VVTi (NRE150_, NRE150R)	1329 CCM	99 HP	01/2010 - 09/2012

COROLLA Saloon (_E15_)

Description	Cylinder Capacity	Horse Power	Year
1.4 VVT-i (ZZE150_)	1398 CCM	97 HP	11/2006 - 11/2013
1.3 (NRE150)	1329 CCM	101 HP	12/2008 - 07/2014

The KYB RH3344 Coil Spring is a replacement suspension spring that supports vehicle load and works with the damper to control suspension movement. Its catalogue specification records front axle fitting position, coil Spring spring design, 12.5 mm thickness 1, and 164 mm outer diameter. It is listed in the suspension Spring product category. Confirm the reference, spring design, dimensions, axle position and vehicle application before fitting; springs should normally be renewed in axle pairs and installed with suitable spring-compression equipment.

Function : Suspension Spring

Fitting Position : Front Axle

Suspension : for vehicles with standard suspension

Spring Design : Coil Spring

Weight [kg] : 1.96

Thickness 1 [mm] : 12.5

Outer Diameter [mm] : 164

Length [mm] : 353
