Napa NBD5639 Brake Disc

SKU: NBD5639

Your selected vehicle

In stock

Order by 17:00 for same-day dispatch

£37.35 inc. VAT

Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

SUZUKI

SWIFT III (FZ, NZ)

Description	Cylinder Capacity	Horse Power	Year
1.2 (AZH412, ZC72S)	1242 CCM	94 HP	10/2010 - 04/2017
1.2 4x4 (AZH412, ZD72S)	1242 CCM	94 HP	10/2010 - 04/2017
1.3 DDiS (AZG413D, ZC02S, ZC92S)	1248 CCM	75 HP	10/2010 - 04/2017
1.2 (AZG412, ZC72S)	1242 CCM	90 HP	10/2010 - 04/2017
1.2 4x4 (AZG412, ZD72S)	1242 CCM	90 HP	10/2010 - 04/2017
1.2 (AZH412, AZG412, ZC72S)	1242 CCM	91 HP	08/2012 - 04/2017
1.2 4WD (AZH412, AZG412, ZD72S)	1242 CCM	91 HP	08/2012 - 04/2017

The Napa NBD5639 Brake Disc is a replacement braking component that provides the rotating friction surface acted on by the pads or shoes. Its catalogue specification records solid disc construction, 259 mm outer diameter, 9 mm brake disc thickness, and rear axle fitting position. Match the reference, diameter, thickness, mounting pattern and vehicle application before fitting; braking components should be installed and checked by a competent person.

Function : Brake Disc

Brake Disc Type : solid

Outer Diameter [mm] : 259

Brake Disc Thickness [mm] : 9

Height [mm] : 43

Bolt Hole Circle Ø [mm] : 100

Centering Diameter [mm] : 62

Number of Holes : 4

Test Mark : 90R-02C01195/25349

Fitting Position : Rear Axle

for article number : NBP1554

Napa NBD5639 Brake Disc
