Napa NBD5642 Brake Disc

SKU: NBD5642

Your selected vehicle

In stock

Order by 17:00 for same-day dispatch

£26.32 inc. VAT

Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

SUZUKI

JIMNY Open Off-Road Vehicle (SN)

Description	Cylinder Capacity	Horse Power	Year
1.3 16V 4WD (SN413, JB33)	1298 CCM	80 HP	From 09/1998
1.3 (SN413)	1328 CCM	86 HP	From 08/2004
1.3 4WD (SN413)	1328 CCM	86 HP	From 03/2013

JIMNY Closed Off-Road Vehicle (SN)

Description	Cylinder Capacity	Horse Power	Year
1.3 16V 4WD (SN413, JB43)	1328 CCM	82 HP	From 02/2001
1.3 16V 4x4 (SN413, JB43)	1328 CCM	86 HP	From 08/2005
1.3 4WD (SN413)	1328 CCM	85 HP	From 05/2014

JIMNY Closed Off-Road Vehicle (A6G)

Description	Cylinder Capacity	Horse Power	Year
1.5 AllGrip (JB74W, JB74V, A6G415)	1462 CCM	102 HP	From 07/2018
1.5 AllGrip (JB74W)	1462 CCM	108 HP	From 01/2019
1.5 XL AllGrip (JC74W)	1462 CCM	102 HP	From 01/2023

The Napa NBD5642 Brake Disc is a replacement braking component that provides the rotating friction surface acted on by the pads or shoes. Its catalogue specification records solid disc construction, 290 mm outer diameter, 10 mm brake disc thickness, and front axle fitting position. Match the reference, diameter, thickness, mounting pattern and vehicle application before fitting; braking components should be installed and checked by a competent person.

Function : Brake Disc

Brake Disc Type : solid

Outer Diameter [mm] : 290

Brake Disc Thickness [mm] : 10

Height [mm] : 46

Bolt Hole Circle Ø [mm] : 140

Centering Diameter [mm] : 108

Number of Holes : 5

Test Mark : 90R-02C0270/0018

Fitting Position : Front Axle

Vehicle Identification Number (VIN) from : 00203805

Napa NBD5642 Brake Disc
