Home / Car Parts / Braking / Brake Pads & Discs / Brake Discs
Napa NBD5648 Brake Disc - 1
Napa NBD5648 Brake Disc - 2
Napa NBD5648 Brake Disc - 1
Napa NBD5648 Brake Disc - 2
NAPA

Napa NBD5648 Brake Disc

SKU: NBD5648
Your selected vehicle
In stock
Order by 17:00 for same-day dispatch
£16.74 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

HONDA
CIVIC IX (FK)
Description Cylinder Capacity Horse Power Year
1.4 i-VTEC (FK1) 1339 CCM 99 HP 02/2012 - 12/2016
1.8 i-VTEC (FK2) 1798 CCM 141 HP 02/2012 - 12/2016
2.2 i-DTEC (FK3) 2199 CCM 150 HP 02/2012 - 12/2016
1.6 i-DTEC (FK3) 1597 CCM 120 HP 02/2013 - 12/2016
CIVIC IX Tourer (FK)
Description Cylinder Capacity Horse Power Year
1.6 i-DTEC (FK3) 1597 CCM 120 HP 01/2014 - 12/2016
1.8 i-VTEC (FK2) 1798 CCM 141 HP 01/2014 - 12/2016

The Napa NBD5648 Brake Disc is a replacement braking component that provides the rotating friction surface acted on by the pads or shoes. Its catalogue specification records solid disc construction, 276 mm outer diameter, 10 mm brake disc thickness, and rear axle fitting position. Match the reference, diameter, thickness, mounting pattern and vehicle application before fitting; braking components should be installed and checked by a competent person.

Function : Brake Disc
Brake Disc Type : solid
Outer Diameter [mm] : 276
Brake Disc Thickness [mm] : 10
Height [mm] : 32
Bolt Hole Circle Ø [mm] : 114
Centering Diameter [mm] : 64
Number of Holes : 5
Test Mark : 90R-02C0270/0251
Fitting Position : Rear Axle
for article number : NBP1616
  • Vendor NAPA
  • SKU NBD5648
  • Barcode 5056536578976
  • HONDA : 42510TV0E00 42510TV0E01
  • APEC : DSK3005
  • APEC : SDK6753
  • BLUE PRINT : ADH243123
  • BORG & BECK : BBD5321
  • Fahren : FBD6753
  • FEBI BILSTEIN : 108479
  • National : NBD1863
