Napa NBD5669 Brake Disc

SKU: NBD5669

Your selected vehicle

In stock

Order by 17:00 for same-day dispatch

£60.28 inc. VAT

Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

FORD

GALAXY III (CK)

Description	Cylinder Capacity	Horse Power	Year
1.5 EcoBoost	1499 CCM	160 HP	01/2015 - 06/2018
2.0 EcoBoost	1999 CCM	240 HP	01/2015 - 04/2023
2.0 TDCi	1997 CCM	120 HP	01/2015 - 06/2018
2.0 TDCi	1997 CCM	150 HP	01/2015 - 06/2018
2.0 TDCi	1997 CCM	180 HP	01/2015 - 06/2018
2.0 TDCi Bi-Turbo	1997 CCM	210 HP	01/2015 - 06/2018
2.0 TDCi 4x4	1997 CCM	150 HP	05/2015 - 06/2018
2.0 TDCi 4x4	1997 CCM	180 HP	05/2015 - 06/2018
2.0 EcoBlue	1995 CCM	120 HP	07/2018 - 04/2023
2.0 EcoBlue	1995 CCM	150 HP	07/2018 - 04/2023
2.0 EcoBlue 4x4	1995 CCM	150 HP	07/2018 - 04/2023
2.0 EcoBlue	1995 CCM	190 HP	07/2018 - 04/2023
2.0 EcoBlue 4x4	1995 CCM	190 HP	07/2018 - 04/2023
2.0 EcoBlue Bi-Turbo	1995 CCM	240 HP	07/2018 - 04/2023

GALAXY MK III VAN (CK)

Description	Cylinder Capacity	Horse Power	Year
2.0 EcoBlue	1995 CCM	150 HP	03/2019 - 04/2023
2.0 EcoBlue AWD	1995 CCM	190 HP	03/2019 - 04/2023

S-MAX (CJ, WA6)

Description	Cylinder Capacity	Horse Power	Year
2.0 EcoBoost	1999 CCM	240 HP	01/2015 - 04/2023
2.0 TDCi	1997 CCM	120 HP	01/2015 - 06/2018
2.0 TDCi	1997 CCM	150 HP	01/2015 - 06/2018
2.0 TDCi 4x4	1997 CCM	150 HP	01/2015 - 06/2018
2.0 TDCi	1997 CCM	180 HP	01/2015 - 06/2018
2.0 TDCi 4x4	1997 CCM	180 HP	01/2015 - 06/2018
2.0 TDCi BI-Turbo	1997 CCM	210 HP	01/2015 - 06/2018
2.0 EcoBlue	1995 CCM	190 HP	07/2018 - 04/2023
2.0 EcoBlue 4x4	1995 CCM	190 HP	07/2018 - 04/2023
2.0 EcoBlue	1995 CCM	120 HP	07/2018 - 04/2023
2.0 EcoBlue	1995 CCM	150 HP	07/2018 - 04/2023
2.0 EcoBlue 4x4	1995 CCM	150 HP	07/2018 - 04/2023

FORD USA

EDGE

Description	Cylinder Capacity	Horse Power	Year
2.0 TDCi AWD	1997 CCM	180 HP	08/2015 - 07/2018
2.0 TDCi Bi-Turbo AWD	1997 CCM	210 HP	08/2015 - 07/2018
2.0 EcoBlue AWD	1995 CCM	190 HP	From 08/2018
2.0 EcoBlue	1995 CCM	150 HP	From 08/2018

The Napa NBD5669 Brake Disc is a replacement braking component that provides the rotating friction surface acted on by the pads or shoes. Its catalogue specification records vented disc construction, 316 mm outer diameter, front axle fitting position, and brake Caliper (2 pistons). Match the reference, diameter, thickness, mounting pattern and vehicle application before fitting; braking components should be installed and checked by a competent person.

Function : Brake Disc

Brake Disc Type : Vented

Outer Diameter [mm] : 316

Brake Disc Thickness [mm] : 32

Height [mm] : 52

Bolt Hole Circle Ø [mm] : 108

Centering Diameter [mm] : 64

Number of Holes : 5

Test Mark : 90R-02C0301/0327

Fitting Position : Front Axle

Brake Caliper Type : Brake Caliper (2 pistons)

for article number : NBP1463
