Napa NBD5714 Brake Disc
Your selected vehicle
Regular price
£48.26
inc. VAT
Pay in 3 interest-free payments with Klarna
Standard delivery
Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.
The Napa NBD5714 Brake Disc is a replacement braking component that provides the rotating friction surface acted on by the pads or shoes. Its catalogue specification records vented disc construction, 282 mm outer diameter, 27 mm brake disc thickness, and 64 mm centering diameter. Match the reference, diameter, thickness, mounting pattern and vehicle application before fitting; braking components should be installed and checked by a competent person.
Function :
Brake Disc
Brake Disc Type :
Vented
Outer Diameter [mm] :
282
Brake Disc Thickness [mm] :
27
Height [mm] :
50
Bolt Hole Circle Ø [mm] :
108
Centering Diameter [mm] :
64
Number of Holes :
5
Machining :
High-carbon
Test Mark :
90R-02C01275/28925
- Vendor NAPA
- SKU NBD5714
- FORD : 2208066 2305503 JX611125AEA
- APEC : DSK3516
- APEC : SDK7141
- BORG & BECK : BBD5550
- DELPHI : BG5296C
- Fahren : FBD7141
- National : NBD2093
