Napa NBD5926 Brake Disc - 1
Napa NBD5926 Brake Disc - 1
NAPA

Napa NBD5926 Brake Disc

SKU: NBD5926
Your selected vehicle
Only 4 left
Low inventory - Hurry! — Order by 17:00 for same-day dispatch
£39.97 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

NISSAN
CUBE (Z11)
Description Cylinder Capacity Horse Power Year
1.4 1386 CCM 98 HP 01/2003 - 11/2008
1.5 1498 CCM 109 HP 01/2003 - 11/2008
CUBE (Z12)
Description Cylinder Capacity Horse Power Year
1.5 dCi 1461 CCM 110 HP From 03/2010
1.6 16V 1598 CCM 110 HP From 08/2009
1.5 dCi 1461 CCM 106 HP From 10/2009
TIIDA Saloon (SC11)
Description Cylinder Capacity Horse Power Year
1.6 (C11L) 1598 CCM 110 HP 09/2007 - 12/2012
1.8 1798 CCM 126 HP 09/2007 - 12/2012
1.5 dCi 1461 CCM 106 HP 09/2007 - 12/2012
1.5 dCi 1461 CCM 103 HP 01/2007 - 12/2012
TIIDA Hatchback (C11)
Description Cylinder Capacity Horse Power Year
1.6 1598 CCM 110 HP 09/2007 - 12/2011
1.8 (JC11) 1798 CCM 126 HP 09/2004 - 12/2011
1.5 dCi 1461 CCM 106 HP 09/2007 - 12/2011
1.5 dCi 1461 CCM 103 HP 03/2007 - 06/2013
NISSAN (DFAC)
TIIDA Saloon (C11)
Description Cylinder Capacity Horse Power Year
1.6 1598 CCM 107 HP From 04/2005

The Napa NBD5926 Brake Disc is a replacement braking component that provides the rotating friction surface acted on by the pads or shoes. Its catalogue specification records solid disc construction, 291 mm outer diameter, 9 mm brake disc thickness, and 68 mm centering diameter. Match the reference, diameter, thickness, mounting pattern and vehicle application before fitting; braking components should be installed and checked by a competent person.

Function : Brake Disc
Brake Disc Type : solid
Outer Diameter [mm] : 291
Brake Disc Thickness [mm] : 9
Height [mm] : 62
Bolt Hole Circle Ø [mm] : 114
Centering Diameter [mm] : 68
Number of Holes : 4
Test Mark : 90R-02C0270/0018
  • Vendor NAPA
  • SKU NBD5926
  • Barcode 5056667439375
  • NISSAN : 43206EM10A
  • BLUE PRINT : ADN143134
  • BORG & BECK : BBD5170
  • DELPHI : BG4666C
