Napa NBD5942 Brake Disc - 1
Napa NBD5942 Brake Disc - 1
NAPA

Napa NBD5942 Brake Disc

SKU: NBD5942
Your selected vehicle
Only 2 left
Low inventory - Hurry! — Order by 17:00 for same-day dispatch
£36.78 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

SUBARU
LEGACY IV (BL)
Description Cylinder Capacity Horse Power Year
2.0 AWD (BL5) 1994 CCM 138 HP 09/2003 - 10/2005
2.5 AWD (BL9) 2457 CCM 165 HP 09/2003 - 04/2009
2.0 AWD (BL5) 1994 CCM 165 HP 06/2005 - 04/2009
2.0 R AWD (BL5) 1994 CCM 150 HP 09/2007 - 12/2009
2.0 D AWD (BLD) 1998 CCM 150 HP 02/2008 - 12/2009
2.5 i AWD (BL9) 2457 CCM 173 HP 09/2007 - 12/2009
LEGACY IV Estate (BP)
Description Cylinder Capacity Horse Power Year
2.0 AWD (BP5) 1994 CCM 138 HP 09/2003 - 10/2005
2.5 AWD (BP9) 2457 CCM 165 HP 09/2003 - 04/2009
2.0 AWD (BP5) 1994 CCM 165 HP 06/2005 - 04/2009
2.5 i AWD (BP9) 2457 CCM 173 HP 01/2008 - 12/2009
2.0 D AWD (BPD) 1998 CCM 150 HP 02/2008 - 12/2009
2.0 R AWD (BP5) 1994 CCM 150 HP 09/2007 - 12/2009
LEGACY V (BM)
Description Cylinder Capacity Horse Power Year
2.0 i LPG AWD 1994 CCM 147 HP 09/2009 - 12/2011
OUTBACK (BP)
Description Cylinder Capacity Horse Power Year
2.5 AWD (BP9) 2457 CCM 165 HP 11/2003 - 09/2009
3.0 AWD (BPE) 3000 CCM 245 HP 11/2003 - 09/2009
2.0 D AWD (BPD) 1998 CCM 150 HP 09/2008 - 09/2009
2.5 AWD (BP9) 2457 CCM 173 HP 09/2008 - 09/2009
2.5 BiFuel AWD 2457 CCM 173 HP 09/2008 - 06/2009

The Napa NBD5942 Brake Disc is a replacement braking component that provides the rotating friction surface acted on by the pads or shoes. Its catalogue specification records solid disc construction, 273 mm outer diameter, 10 mm brake disc thickness, and 58 mm centering diameter. Match the reference, diameter, thickness, mounting pattern and vehicle application before fitting; braking components should be installed and checked by a competent person.

Function : Brake Disc
Brake Disc Type : solid
Outer Diameter [mm] : 273
Brake Disc Thickness [mm] : 10
Height [mm] : 67
Bolt Hole Circle Ø [mm] : 100
Centering Diameter [mm] : 58
Number of Holes : 5
Test Mark : 90R-02C0357/1471
  • Vendor NAPA
  • SKU NBD5942
  • Barcode 5056667439535
  • SUBARU : 26700AG000 26700AG001 26700AG01B
  • BLUE PRINT : ADS74324
  • BORG & BECK : BBD4764
  • FEBI BILSTEIN : 170764
  • National : NBD1606
