Napa NCS1125 Coil Spring

5.0/5 60 AutoMotoPart customer reviews Verified reviews across our products & service

SKU: NCS1125

Check product compatibility

Enter your registration or select your vehicle to check this product fits.

Only 5 left

Low inventory - Hurry! — Orders placed by 17:00 are usually dispatched the same working day

£31.05 inc. VAT

Pay in 3 interest-free payments with Klarna

Free UK mainland standard delivery 14-day returns

Need help choosing the right part? Call 01472 869 066

FORD

MONDEO III (B5Y)

Description	Cylinder Capacity	Horse Power	Year
1.8 16V	1798 CCM	110 HP	10/2000 - 03/2007
1.8 16V	1798 CCM	125 HP	10/2000 - 03/2007
2.0 16V	1999 CCM	146 HP	10/2000 - 03/2007
2.5 V6 24V	2495 CCM	170 HP	10/2000 - 03/2007
2.0 16V DI / TDDi / TDCi	1998 CCM	90 HP	10/2000 - 03/2007
2.0 16V TDDi / TDCi	1998 CCM	115 HP	10/2000 - 03/2007
2.0 TDCi	1998 CCM	130 HP	10/2001 - 03/2007
1.8 SCi	1798 CCM	130 HP	06/2003 - 03/2007
2.2 TDCi	2198 CCM	155 HP	09/2004 - 03/2007
3.0 V6 24V	2967 CCM	204 HP	09/2004 - 03/2007
2.2 TDCi	2198 CCM	150 HP	09/2004 - 03/2007
2.0 DI	1998 CCM	125 HP	10/2000 - 03/2007

MONDEO Mk III Saloon (B4Y)

Description	Cylinder Capacity	Horse Power	Year
1.8 16V	1798 CCM	110 HP	10/2000 - 03/2007
1.8 16V	1798 CCM	125 HP	10/2000 - 03/2007
2.0 16V	1999 CCM	146 HP	10/2000 - 03/2007
2.5 V6 24V	2495 CCM	170 HP	10/2000 - 03/2007
2.0 16V DI / TDDi / TDCi	1998 CCM	90 HP	10/2000 - 03/2007
2.0 16V TDDi / TDCi	1998 CCM	115 HP	10/2000 - 03/2007
2.0 TDCi	1998 CCM	130 HP	10/2001 - 03/2007
1.8 SCi	1798 CCM	130 HP	06/2003 - 03/2007
2.2 TDCi	2198 CCM	155 HP	09/2004 - 03/2007
3.0 V6 24V	2967 CCM	204 HP	09/2004 - 03/2007
2.2 TDCi	2198 CCM	150 HP	09/2004 - 03/2007
2.0 DI	1998 CCM	125 HP	10/2000 - 03/2007
2.5 V6	2495 CCM	170 HP	10/2000 - 03/2007

The Napa NCS1125 Coil Spring is a replacement suspension spring that supports vehicle load and works with the damper to control suspension movement. Its catalogue specification records coil spring with inconstant wire diameter spring design, 394 mm length, 138 mm outer diameter, and 11.8 mm thickness. It is listed in the suspension Spring product category. Confirm the reference, spring design, dimensions, axle position and vehicle application before fitting; springs should normally be renewed in axle pairs and installed with suitable spring-compression equipment.

Function : Suspension Spring

Spring Design : Coil spring with inconstant wire diameter

Length [mm] : 394

Outer Diameter [mm] : 138

Thickness [mm] : 11.8

Thickness 1 [mm] : 12
