Napa NCS1583 Suspension Spring - 1
Napa NCS1583 Suspension Spring - 1
NAPA

Napa NCS1583 Coil Spring

SKU: NCS1583
Your selected vehicle
In stock
Orders placed by 17:00 are usually dispatched the same working day
£28.52 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery on UK mainland orders. See our delivery information for coverage and current dispatch estimates.

FORD
MONDEO IV (BA7)
Description Cylinder Capacity Horse Power Year
2.0 TDCi 1997 CCM 136 HP 03/2007 - 12/2014
1.6 TDCi 1560 CCM 115 HP 02/2011 - 01/2015
2.5 2521 CCM 220 HP 03/2007 - 01/2015
1.8 TDCi 1753 CCM 100 HP 03/2007 - 01/2015
2.0 TDCi 1997 CCM 130 HP 03/2007 - 01/2015
2.0 TDCi 1997 CCM 140 HP 03/2007 - 01/2015
2.3 2261 CCM 160 HP 07/2007 - 01/2015
MONDEO IV Turnier (BA7)
Description Cylinder Capacity Horse Power Year
2.0 TDCi 1997 CCM 136 HP 03/2007 - 12/2014
1.6 TDCi 1560 CCM 115 HP 02/2011 - 01/2015
2.5 2521 CCM 220 HP 03/2007 - 12/2012
1.8 TDCi 1753 CCM 100 HP 03/2007 - 12/2012
2.0 TDCi 1997 CCM 130 HP 03/2007 - 12/2012
2.0 TDCi 1997 CCM 140 HP 03/2007 - 01/2015
MONDEO IV Saloon (BA7)
Description Cylinder Capacity Horse Power Year
2.5 2521 CCM 220 HP 03/2007 - 01/2015
2.0 TDCi 1997 CCM 130 HP 03/2007 - 01/2015
2.0 TDCi 1997 CCM 140 HP 03/2007 - 01/2015
2.3 2261 CCM 160 HP 07/2007 - 01/2015
2.0 TDCi 1997 CCM 115 HP 11/2007 - 01/2015
1.8 TDCi 1753 CCM 125 HP 06/2007 - 01/2015
1.8 TDCi 1753 CCM 100 HP 03/2007 - 01/2015
1.6 TDCi 1560 CCM 115 HP 12/2010 - 01/2015

The Napa NCS1583 Coil Spring is a replacement suspension spring that supports vehicle load and works with the damper to control suspension movement. Its catalogue specification records coil spring with inconstant wire diameter spring design, 386 mm length, 166 mm outer diameter, and 13.5 mm thickness. It is listed in the suspension Spring product category. Confirm the reference, spring design, dimensions, axle position and vehicle application before fitting; springs should normally be renewed in axle pairs and installed with suitable spring-compression equipment.

Function : Suspension Spring
Spring Design : Coil spring with inconstant wire diameter
Length [mm] : 386
Outer Diameter [mm] : 166
Thickness [mm] : 13.5
Thickness 1 [mm] : 14
  • Vendor NAPA
  • SKU NCS1583
  • Barcode 5056373864003
  • FORD : 1460419 1465194 1465195 1470875 1474294 6G915310ACB 6G915310ACC 6G915310ACD 6G915310BBC 6G915310BBD
  • APEC : ACS1583
  • MONROE : SP3747
