Napa NCS1587 Suspension Spring - 1
Napa NCS1587 Suspension Spring - 1
NAPA

Napa NCS1587 Coil Spring

SKU: NCS1587
Your selected vehicle
Only 5 left
Low inventory - Hurry! — Orders placed by 17:00 are usually dispatched the same working day
£28.62 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery on UK mainland orders. See our delivery information for coverage and current dispatch estimates.

MERCEDES-BENZ
C-CLASS (W202)
Description Cylinder Capacity Horse Power Year
C 200 D (202.120) 1997 CCM 75 HP 03/1993 - 05/2000
C 220 D (202.121) 2155 CCM 95 HP 08/1993 - 05/2000
C 180 (202.018) 1799 CCM 122 HP 03/1993 - 05/2000
C 220 (202.022) 2199 CCM 150 HP 03/1993 - 05/2000
C 200 (202.020) 1998 CCM 136 HP 01/1994 - 05/2000
C 180 (202.018) 1799 CCM 121 HP 11/1994 - 05/2000
C 200 Kompressor (202.025) 1998 CCM 180 HP 10/1995 - 05/2000
C 200 D (202.122) 1997 CCM 88 HP 10/1996 - 05/2000
C 200 Kompressor (202.025) 1998 CCM 192 HP 11/1996 - 05/2000
C-CLASS T-Model (S202)
Description Cylinder Capacity Horse Power Year
C 180 T (202.078) 1799 CCM 122 HP 06/1996 - 09/2000
C 200 T (202.080) 1998 CCM 136 HP 06/1996 - 03/2001
C 220 T D (202.182) 2155 CCM 95 HP 06/1996 - 09/1998
C 200 T D (202.180) 1997 CCM 88 HP 10/1996 - 03/2001
C 200 T Kompressor (202.082) 1998 CCM 192 HP 11/1996 - 03/2001
C 220 T D (202.182) 2155 CCM 75 HP 06/1996 - 03/2001
C 180 T (202.081) 1998 CCM 129 HP 09/2000 - 03/2001
SLK (R170)
Description Cylinder Capacity Horse Power Year
200 (170.435) 1998 CCM 136 HP 09/1996 - 03/2000
230 Kompressor (170.447) 2295 CCM 193 HP 09/1996 - 03/2000
200 Kompressor (170.445) 1998 CCM 192 HP 10/1996 - 03/2000
200 Kompressor (170.444) 1998 CCM 163 HP 03/2000 - 04/2004
230 Kompressor (170.449) 2295 CCM 197 HP 03/2000 - 04/2004

The Napa NCS1587 Coil Spring is a replacement suspension spring that supports vehicle load and works with the damper to control suspension movement. Its catalogue specification records coil spring with inconstant wire diameter spring design, 362 mm length, 109 mm outer diameter, and 13.5 mm thickness. It is listed in the suspension Spring product category. Confirm the reference, spring design, dimensions, axle position and vehicle application before fitting; springs should normally be renewed in axle pairs and installed with suitable spring-compression equipment.

Function : Suspension Spring
Spring Design : Coil spring with inconstant wire diameter
Length [mm] : 362
Outer Diameter [mm] : 109
Thickness [mm] : 13.5
Thickness 1 [mm] : 14
  • Vendor NAPA
  • SKU NCS1587
  • Barcode 5056373864041
  • MERCEDES-BENZ : 1703210004 2023211504 A1703210004 A2023211504
  • APEC : ACS1587
  • MONROE : SP1448
