Napa NCS1758 Coil Spring

SKU: NCS1758

Your selected vehicle

Only 3 left

Low inventory - Hurry! — Orders placed by 17:00 are usually dispatched the same working day

£24.81 inc. VAT

Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery on UK mainland orders. See our delivery information for coverage and current dispatch estimates.

FORD

C-MAX II (DXA/CB7, DXA/CEU)

Description	Cylinder Capacity	Horse Power	Year
2.0 TDCi	1997 CCM	163 HP	12/2010 - 06/2019
2.0 TDCi	1997 CCM	115 HP	02/2011 - 06/2019
2.0 TDCi	1997 CCM	140 HP	04/2010 - 06/2019
2.0 TDCi	1997 CCM	136 HP	02/2011 - 06/2019

C-MAX II Van

Description	Cylinder Capacity	Horse Power	Year
2.0 TDCi	1997 CCM	163 HP	12/2010 - 06/2019
2.0 TDCi	1997 CCM	170 HP	03/2015 - 06/2019

MAZDA

5 (CR)

Description	Cylinder Capacity	Horse Power	Year
1.8 (CR19)	1798 CCM	116 HP	02/2005 - 05/2010
2.0 (CREW, CR19)	1999 CCM	146 HP	02/2005 - 05/2010

The Napa NCS1758 Coil Spring is a replacement suspension spring that supports vehicle load and works with the damper to control suspension movement. Its catalogue specification records coil spring with inconstant wire diameter spring design, 338 mm length, 158 mm outer diameter, and 13.5 mm thickness. It is listed in the suspension Spring product category. Confirm the reference, spring design, dimensions, axle position and vehicle application before fitting; springs should normally be renewed in axle pairs and installed with suitable spring-compression equipment.

Function : Suspension Spring

Spring Design : Coil spring with inconstant wire diameter

Length [mm] : 338

Outer Diameter [mm] : 158

Thickness [mm] : 13.5

Thickness 1 [mm] : 14
