Napa NCS1943 Coil Spring

SKU: NCS1943

Your selected vehicle

Only 4 left

Low inventory - Hurry! — Orders placed by 17:00 are usually dispatched the same working day

£28.28 inc. VAT

Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery on UK mainland orders. See our delivery information for coverage and current dispatch estimates.

FIAT

MULTIPLA (186_)

Description	Cylinder Capacity	Horse Power	Year
1.6 100 16V (186AXA1A)	1581 CCM	103 HP	04/1999 - 08/2000
1.9 JTD 105 (186AXB1A)	1910 CCM	105 HP	04/1999 - 08/2000
1.6 Blupower (186AMA1A)	1581 CCM	95 HP	04/1999 - 09/2004
1.6 16V Bipower (186AMB1A)	1581 CCM	103 HP	04/1999 - 09/2004
1.9 JTD 110	1910 CCM	110 HP	03/2001 - 07/2002
1.6 16V Bipower (186AXC1A)	1596 CCM	103 HP	10/2001 - 08/2005
1.9 JTD 115	1910 CCM	115 HP	07/2002 - 06/2010
1.6 16V (186AGB1A)	1596 CCM	95 HP	04/2002 - 06/2010
1.9 JTD (186AXE1A)	1910 CCM	120 HP	04/2002 - 06/2010
1.6	1596 CCM	92 HP	05/2004 - 08/2005
1.6 (186AXC1A, 186BMC1A, 186BXC1A)	1596 CCM	103 HP	09/2000 - 06/2010

The Napa NCS1943 Coil Spring is a replacement suspension spring that supports vehicle load and works with the damper to control suspension movement. Its catalogue specification records coil spring with inconstant wire diameter spring design, 436 mm length, 178 mm outer diameter, and 13.5 mm thickness. It is listed in the suspension Spring product category. Confirm the reference, spring design, dimensions, axle position and vehicle application before fitting; springs should normally be renewed in axle pairs and installed with suitable spring-compression equipment.

Function : Suspension Spring

Spring Design : Coil spring with inconstant wire diameter

Length [mm] : 436

Outer Diameter [mm] : 178

Thickness [mm] : 13.5

Thickness 1 [mm] : 14
