Napa NSM1560 Starter - 1
Napa NSM1560 Starter - 1
NAPA

Napa NSM1560 Starter Motor

5.0/5 60 AutoMotoPart customer reviews Verified reviews across our products & service
SKU: NSM1560

Check product compatibility

Enter your registration or select your vehicle to check this product fits.

Out of stock
Out of Stock
£115.73 inc. VAT
Pay in 3 interest-free payments with Klarna
Free UK mainland standard delivery 14-day returns

Need help choosing the right part? Call 01472 869 066

JAGUAR
F-TYPE Convertible (X152)
Description Cylinder Capacity Horse Power Year
3.0 SCV6 2995 CCM 340 HP From 10/2012
3.0 SCV6 S 2995 CCM 380 HP From 10/2012
5.0 SCV8 S 5000 CCM 495 HP From 10/2012
3.0 SCV6 S AWD 2995 CCM 380 HP From 12/2014
5.0 SCV8 R 5000 CCM 551 HP From 10/2013
5.0 SCV8 R AWD 5000 CCM 551 HP From 12/2014
5.0 SCV8 SVR / SCV8 P575 R AWD 5000 CCM 575 HP From 12/2015
SCV6 400 SPORT 2995 CCM 400 HP From 11/2016
SCV6 400 SPORT AWD 2995 CCM 400 HP From 11/2016
5.0 SCV8 SVR 5000 CCM 575 HP From 05/2015
5.0 SCV8 P450 5000 CCM 450 HP From 12/2019
5.0 SCV8 P450 AWD 5000 CCM 450 HP From 12/2019
F-TYPE Coupe (X152)
Description Cylinder Capacity Horse Power Year
3.0 SCV6 2995 CCM 340 HP From 10/2013
3.0 SCV6 S 2995 CCM 380 HP From 10/2013
5.0 SCV8 R 5000 CCM 551 HP From 10/2013
3.0 SCV6 S AWD 2995 CCM 380 HP From 12/2014
5.0 SCV8 R AWD 5000 CCM 551 HP From 12/2014
5.0 SCV8 SVR / SCV8 P575 R 5000 CCM 575 HP From 12/2015
3.0 SCV6 400 SPORT 2995 CCM 400 HP From 11/2016
3.0 SCV6 400 SPORT AWD 2995 CCM 400 HP From 11/2016
5.0 SCV8 P450 5000 CCM 450 HP From 12/2019
5.0 SCV8 P450 AWD 5000 CCM 450 HP From 12/2019
XF I (X250)
Description Cylinder Capacity Horse Power Year
5.0 Kompressor 5000 CCM 471 HP 01/2009 - 04/2015
5.0 5000 CCM 385 HP 03/2009 - 04/2015
5.0 Kompressor 5000 CCM 510 HP 03/2009 - 04/2015
XF SPORTBRAKE (X250)
Description Cylinder Capacity Horse Power Year
5.0 XFR-S 5000 CCM 550 HP 02/2013 - 04/2014
XJ (X351)
Description Cylinder Capacity Horse Power Year
5.0 SCV8 5000 CCM 471 HP 10/2009 - 12/2019
5.0 SCV8 5000 CCM 550 HP 06/2013 - 12/2019
5.0 V8 5000 CCM 385 HP 10/2009 - 12/2019
5.0 SCV8 5000 CCM 510 HP 10/2009 - 12/2019
5.0 SCV8 R575 5000 CCM 575 HP 06/2017 - 12/2019

The Napa NSM1560 Starter Motor is a replacement starting or charging-system component that supports electrical power generation, storage or engine cranking in the vehicle. Its catalogue specification records 12 V electrical rating, 1.8 kW rated power, 3,150 mm length, and 9 teeth. Match the reference, voltage, output or capacity, terminals, mounting and vehicle application before fitting; isolate the electrical system and follow the manufacturer's coding procedure where required.

Function : Starter
Voltage [V] : 12
Rated Power [kW] : 1.8
Length [mm] : 3,150
Width [mm] : 1,801
Height [mm] : 1,450
Manufacturer Restriction : Denso
Number of Teeth : 9
Vehicle Equipment : for vehicles without start-stop function
  • Vendor NAPA
  • SKU NSM1560
  • Barcode 5056500663646
  • FORD : 8W83-11001-BB
  • JAGUAR : 8W8311001BB 8W83-11001-BB 8W8311001BC 8W83-11001-BC 8W8311001BD 8W83-11001-BD C2D19967 C2D27864 C2D3536 C2D51166 C2P26075 DX2311001AC DX23-11001-AC
  • APEC : ASM1560
  • WAI : 19923N
  • WAI : S136.039
