NRF 320295 Compressor, air conditioning

SKU: 320295

Your selected vehicle

Only 1 left

Low inventory - Hurry! — Order by 17:00 for same-day dispatch

£325.43 inc. VAT

Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

MAZDA

6 Estate (GJ, GL)

Description	Cylinder Capacity	Horse Power	Year
2.2 D (GJ2FW, GJ692)	2191 CCM	175 HP	08/2012 - 02/2018
2.2 D	2191 CCM	150 HP	10/2012 - 12/2020
2.2 D AWD	2191 CCM	175 HP	From 02/2015
2.2 D AWD	2191 CCM	150 HP	12/2012 - 12/2020
2.2 D	2191 CCM	184 HP	03/2018 - 12/2020
2.2 D AWD	2191 CCM	184 HP	03/2018 - 12/2020

6 Saloon (GJ, GL)

Description	Cylinder Capacity	Horse Power	Year
2.2 D (GJ2FP, GJ1021, GJ1022, GL1021)	2191 CCM	175 HP	From 12/2012
2.2 D (GJ2FP)	2191 CCM	150 HP	12/2012 - 11/2020
2.2 D	2191 CCM	184 HP	03/2018 - 11/2020

CX-5 (KE, GH)

Description	Cylinder Capacity	Horse Power	Year
2.2 D (KE2FW)	2191 CCM	150 HP	04/2012 - 02/2017
2.2 D AWD (KE2AW)	2191 CCM	150 HP	04/2012 - 02/2017
2.2 D AWD (KE102)	2191 CCM	175 HP	04/2012 - 02/2017

CX-5 (KF)

Description	Cylinder Capacity	Horse Power	Year
2.0	1998 CCM	165 HP	From 05/2017
2.0 AWD	1998 CCM	160 HP	From 05/2017
2.5 AWD	2488 CCM	194 HP	From 05/2017
2.2 D AWD (KF4W2)	2191 CCM	175 HP	05/2017 - 02/2018
2.2 D AWD	2191 CCM	188 HP	From 03/2018
2.2 D AWD	2191 CCM	184 HP	From 06/2018

The NRF 320295 Compressor, air conditioning is a replacement heating, ventilation or air-conditioning component that supports refrigerant heat exchange or controlled airflow within the vehicle climate system. Its catalogue specification records 100 ml oil fill quantity, 18.3 mm inlet diameter, 15.5 mm outlet diameter, and with seal ring. Match the reference, refrigerant-system specification, dimensions, connections, electrical details and vehicle application before fitting; refrigerant work must be carried out with approved recovery and charging equipment.

Function : Compressor, air conditioning

Manufacturer Restriction : HALLA-EQUIVALENT

Pulleys : with belt pulley

Compressor ID : RS18

Refrigerant : R 1234yf

Refrigerant : R 134a

Compressor Oil : PAG 46 YF

Number of grooves : 6

Belt Pulley Ø [mm] : 111

Oil Fill Quantity [ml] : 100

Inlet Diameter [mm] : 18.3

Outlet Diameter [mm] : 15.5

Quality : OE-EQUIVALENT

Connector Shape : rectangular

Supplementary Article/Supplementary Info 2 : with seal ring
