NRF 32688G Compressor, air conditioning

SKU: 32688G
Your selected vehicle
Out of stock
Out of Stock
£586.73 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

MAZDA
3 (BL)
Description Cylinder Capacity Horse Power Year
2.2 MZR CD (BL10) 2184 CCM 150 HP 01/2009 - 10/2013
2.2 MZR CD (BL10) 2184 CCM 185 HP 01/2009 - 05/2013
3 Saloon (BL)
Description Cylinder Capacity Horse Power Year
2.2 MZR CD (BL10) 2184 CCM 150 HP 01/2009 - 09/2014
2.2 MZR CD (BL10) 2184 CCM 185 HP 06/2009 - 05/2013
6 Saloon (GH)
Description Cylinder Capacity Horse Power Year
2.0 MZR-CD (GH14) 1998 CCM 140 HP 08/2007 - 10/2010
2.2 MZR-CD (GH10) 2184 CCM 125 HP 01/2009 - 12/2012
2.2 MZR-CD (GH10) 2184 CCM 163 HP 01/2009 - 12/2012
2.2 MZR-CD (GH10) 2184 CCM 185 HP 01/2009 - 12/2012
2.2 D (GH10) 2184 CCM 129 HP 01/2010 - 12/2012
2.2 D (GH10) 2183 CCM 180 HP 01/2010 - 07/2013
6 Hatchback (GH)
Description Cylinder Capacity Horse Power Year
2.2 MZR-CD (GH10) 2184 CCM 180 HP 01/2010 - 12/2012
2.2 D (GH10) 2184 CCM 129 HP 01/2010 - 12/2012
2.0 MZR-CD (GH14) 1998 CCM 140 HP 08/2007 - 10/2009
2.2 MZR-CD (GH10) 2184 CCM 185 HP 01/2009 - 12/2012
2.2 MZR-CD (GH10) 2184 CCM 163 HP 01/2009 - 12/2012
2.2 MZR-CD (GH10) 2184 CCM 125 HP 01/2009 - 12/2012
6 Estate (GH)
Description Cylinder Capacity Horse Power Year
2.2 D (GH10) 2184 CCM 129 HP 01/2010 - 07/2013
2.2 MZR-CD (GH10) 2183 CCM 180 HP 01/2010 - 07/2013
2.0 MZR-CD (GH14) 1998 CCM 140 HP 12/2007 - 12/2010
2.2 MZR-CD (GH10) 2184 CCM 125 HP 01/2009 - 12/2010
2.2 MZR-CD (GH10) 2184 CCM 163 HP 08/2008 - 07/2013
2.2 MZR-CD (GH10) 2184 CCM 185 HP 08/2008 - 12/2011

The NRF 32688G Compressor, air conditioning is a replacement heating, ventilation or air-conditioning component that supports refrigerant heat exchange or controlled airflow within the vehicle climate system. Its catalogue specification records with PAG compressor oil and with seal ring, 12 V electrical rating, 18.3 mm inlet diameter, and 15.5 mm outlet diameter. Match the reference, refrigerant-system specification, dimensions, connections, electrical details and vehicle application before fitting; refrigerant work must be carried out with approved recovery and charging equipment.

Function : Compressor, air conditioning
Manufacturer Restriction : GENUINE PANASONIC
Supplementary Article/Supplementary Info 2 : with PAG compressor oil
Pulleys : with V-ribbed belt pulley
Compressor ID : H12
Voltage [V] : 12
Compressor Oil : PAG 46
Number of grooves : 8
Belt Pulley Ø [mm] : 119
Oil Fill Quantity [ml] : 150
Inlet Diameter [mm] : 18.3
Outlet Diameter [mm] : 15.5
Connector Shape : rectangular
Supplementary Article/Supplementary Info 2 : with seal ring
  • Vendor NRF
  • SKU 32688G
  • Barcode 8718042136466
  • MAZDA : GAM661K00 GDB161450 H12A0CA4JE H12A1AQ4HE
  • LUCAS : ACP910
