NRF

NRF 32858A Compressor, air conditioning

SKU: 32858A
Your selected vehicle
Only 2 left
Low inventory - Hurry! — Order by 17:00 for same-day dispatch
Regular price £267.21 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

TOYOTA
HILUX VIGO VII Pickup (_N1_, _N2_, _N3_)
Description Cylinder Capacity Horse Power Year
2.5 D-4D (KUN15, KUN35) 2494 CCM 144 HP 01/2010 - 05/2015
2.5 D 4WD (KUN25) 2494 CCM 102 HP 03/2005 - 05/2015
2.5 D-4D 4WD (KUN25_, KUN25R) 2494 CCM 120 HP 06/2006 - 05/2015
2.5 D-4D (KUN15_, KUN15R) 2494 CCM 120 HP 06/2006 - 05/2015
3.0 D-4D 4WD (KUN26) 2982 CCM 171 HP 08/2005 - 09/2015
2.5 D-4D (KUN15, KUN10) 2494 CCM 102 HP 03/2005 - 05/2015
3.0 D-4D 4WD (KUN26) 2982 CCM 163 HP 03/2005 - 05/2015
2.5 D-4D 4WD (KUN25) 2494 CCM 144 HP 12/2007 - 05/2015
2.5 D-4D 4WD (KUN25_) 2494 CCM 128 HP 11/2004 - 12/2005
3.0 D-4D 4WD (KUN26) 2982 CCM 197 HP 05/2008 - 12/2012
2.5 D-4D (KUN15) 2494 CCM 88 HP 08/2005 - 10/2006

The NRF 32858A Compressor, air conditioning is a replacement heating, ventilation or air-conditioning component that supports refrigerant heat exchange or controlled airflow within the vehicle climate system. Its catalogue specification records 12 V electrical rating, 18.3 mm inlet diameter, 15.5 mm outlet diameter, and Hilux vehicle type. Match the reference, refrigerant-system specification, dimensions, connections, electrical details and vehicle application before fitting; refrigerant work must be carried out with approved recovery and charging equipment.

Function : Compressor, air conditioning
Manufacturer Restriction : DENSO-EQUIVALENT
Pulleys : with V-ribbed belt pulley
Compressor ID : 10S11C
Voltage [V] : 12
Compressor Oil : PAG 46
Number of grooves : 7
Belt Pulley Ø [mm] : 120
Oil Fill Quantity [ml] : 120
Inlet Diameter [mm] : 18.3
Outlet Diameter [mm] : 15.5
Quality : OE-EQUIVALENT
Supplementary Article/Supplementary Info 2 : with seal ring
Vehicle type : Hilux
  • Vendor NRF
  • SKU 32858A
  • Barcode 8718042324849
  • TOYOTA : 883100K110 883100K111 883100K112 883100K113 883100K114 883200K080 883200K380
  • User manual
