NRF

NRF 350361 Condenser, air conditioning

SKU: 350361
Your selected vehicle
In stock
Order by 17:00 for same-day dispatch
£90.58 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

MAZDA
2 Hatchback (DL, DJ)
Description Cylinder Capacity Horse Power Year
1.5 SKYACTIV-G (DJLFS) 1496 CCM 115 HP From 08/2014
1.5 1496 CCM 75 HP From 08/2014
1.5 SKYACTIV-G 1496 CCM 90 HP From 08/2014
1.5 (DJ2HA) 1496 CCM 107 HP From 11/2014
1.5 SKYACTIV-G M Hybrid 1496 CCM 90 HP From 08/2019
1.5 SKYACTIV-G M Hybrid 1496 CCM 75 HP From 08/2019
CX-3 (DK)
Description Cylinder Capacity Horse Power Year
2.0 SKYACTIV-G (DK5W, DK6W) 1998 CCM 120 HP From 05/2015
2.0 SKYACTIV-G AWD (DK4W7, DKEAW) 1998 CCM 150 HP From 05/2015
2.0 SKYACTIV-G 1998 CCM 121 HP From 02/2018
2.0 SKYACTIV-G (DK2W7, DKEFW) 1998 CCM 150 HP From 05/2018

The NRF 350361 Condenser, air conditioning is a replacement heating, ventilation or air-conditioning component that supports refrigerant heat exchange or controlled airflow within the vehicle climate system. Its catalogue specification records with dryer and with seal ring, aluminium construction, 15.5 mm inlet diameter, and 10.1 mm outlet diameter. Match the reference, refrigerant-system specification, dimensions, connections, electrical details and vehicle application before fitting; refrigerant work must be carried out with approved recovery and charging equipment.

Function : Condenser, air conditioning
Supplementary Article/Supplementary Info 2 : with dryer
Material : Aluminium
Supplementary Article/Supplementary Info : with nitrogen filling
Core Length [mm] : 602
Core Width [mm] : 345
Core Depth [mm] : 12
Chemical Properties : Corrosion resistant
Inlet Diameter [mm] : 15.5
Outlet Diameter [mm] : 10.1
Supplementary Article/Supplementary Info 2 : with seal ring
  • Vendor NRF
  • SKU 350361
  • Barcode 8718042307491
  • MAZDA : D09W61480 D09W61480A DB3R61480 DB3R61480A DB5H61480A DB9L61480A DF7B61480 DF7B61480A
  • TOYOTA : 88460WB001
  • APEC : BCY1259
  • APEC : BWC8056
  • BOSCH : 0 204 116 109
  • BOSCH : F 026 002 109
  • BREMBO : A 12 029
  • DELPHI : LW21796
  • DENSO : DCN44017
  • DENSO : DCN44018
  • FEBI BILSTEIN : 39740
  • FTE : 9210241
  • HELLA : 8AW 355 533-011
  • HELLA : 8FC 366 222-201
  • MAHLE : AC 1100 000S
  • MEYLE : 16-14 531 0011
  • TRW : BWH175
  • VALEO : 822589
