NRF 35749 Condenser, air conditioning - 1
NRF 35749 Condenser, air conditioning - 2
NRF 35749 Condenser, air conditioning - 3
NRF 35749 Condenser, air conditioning - 4
NRF 35749 Condenser, air conditioning - 5
NRF 35749 Condenser, air conditioning - 6
NRF 35749 Condenser, air conditioning - 1
NRF 35749 Condenser, air conditioning - 2
NRF 35749 Condenser, air conditioning - 3
NRF 35749 Condenser, air conditioning - 4
NRF 35749 Condenser, air conditioning - 5
NRF 35749 Condenser, air conditioning - 6
NRF

NRF 35749 Condenser, air conditioning

SKU: 35749
Your selected vehicle
Only 3 left
Low inventory - Hurry! — Order by 17:00 for same-day dispatch
£91.81 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

RENAULT
ESPACE Mk IV (JK0/1_)
Description Cylinder Capacity Horse Power Year
2.0 Turbo (JK0A, JK0B, JK0N) 1998 CCM 163 HP 11/2002 - 02/2006
2.2 dCi (JK0H) 2188 CCM 150 HP 11/2002 - 08/2006
3.5 V6 (JK00, JK0F, JK0P, JK0S, JK0W) 3498 CCM 241 HP 11/2002 - 12/2015
3.0 dCi (JK0J, JK0V) 2958 CCM 177 HP 11/2002 - 08/2006
2.0 (JK09) 1998 CCM 136 HP 11/2002 - 01/2015
1.9 dCi (JK0U, JK0G) 1870 CCM 120 HP 11/2002 - 01/2015
2.0 (JK0A, JK1D, JK0N) 1998 CCM 170 HP 04/2005 - 12/2015
2.0 dCi (JK01, JK02, JK1J, JK1K, JK1H) 1995 CCM 150 HP 01/2006 - 12/2015
2.0 dCi (JK03, JK04, JK1C, JK1G, JK1J, JK1K) 1995 CCM 173 HP 01/2006 - 12/2015
3.0 dCi (JK0E, JK0Y) 2958 CCM 181 HP 01/2006 - 01/2015
2.2 dCi (JK07) 2188 CCM 139 HP 02/2006 - 12/2015
1.9 dCi (JK0U) 1870 CCM 116 HP 04/2003 - 02/2005
2.0 dCi (JK02, JK03) 1995 CCM 131 HP 01/2006 - 12/2015
2.0 (JK0K) 1998 CCM 133 HP 11/2002 - 12/2015

The NRF 35749 Condenser, air conditioning is a replacement heating, ventilation or air-conditioning component that supports refrigerant heat exchange or controlled airflow within the vehicle climate system. Its catalogue specification records aluminium construction, with nitrogen filling, 15.5 mm inlet diameter, and 15.5 mm outlet diameter. Match the reference, refrigerant-system specification, dimensions, connections, electrical details and vehicle application before fitting; refrigerant work must be carried out with approved recovery and charging equipment.

Function : Condenser, air conditioning
Material : Aluminium
Supplementary Article/Supplementary Info : with nitrogen filling
Core Length [mm] : 650
Core Width [mm] : 431
Core Depth [mm] : 18
Chemical Properties : Corrosion resistant
Inlet Diameter [mm] : 15.5
Outlet Diameter [mm] : 15.5
Supplementary Article/Supplementary Info 2 : with seal ring
Construction Year from : 04.2004
  • Vendor NRF
  • SKU 35749
  • Barcode 8718042025487
  • RENAULT : 8200332851 8660003448
  • BLUE PRINT : ADK88628
  • BORG & BECK : BCA7791
  • CORTECO : 601414
  • CORTECO : 601415
  • CORTECO : 80000392
  • DELPHI : TSP0225639
  • DENSO : DCN23021
  • FEBI BILSTEIN : 01941
  • FEBI BILSTEIN : 03798
  • FEBI BILSTEIN : 07023
  • FEBI BILSTEIN : 09151
  • FEBI BILSTEIN : 09154
  • FEBI BILSTEIN : 42288
  • FIRST LINE : FCA7791
  • GATES : ETM1346
  • MAHLE : AC 365 000P
  • MAHLE : AC 365 000S
  • TEXTAR : 45067000
  • VALEO : 814007
