NRF 35864 Condenser, air conditioning - 1
NRF 35864 Condenser, air conditioning - 2
NRF 35864 Condenser, air conditioning - 3
NRF 35864 Condenser, air conditioning - 4
NRF 35864 Condenser, air conditioning - 5
NRF 35864 Condenser, air conditioning - 6
NRF 35864 Condenser, air conditioning - 1
NRF 35864 Condenser, air conditioning - 2
NRF 35864 Condenser, air conditioning - 3
NRF 35864 Condenser, air conditioning - 4
NRF 35864 Condenser, air conditioning - 5
NRF 35864 Condenser, air conditioning - 6
NRF

NRF 35864 Condenser, air conditioning

5.0/5 60 AutoMotoPart customer reviews Verified reviews across our products & service
SKU: 35864

Check product compatibility

Enter your registration or select your vehicle to check this product fits.

Only 4 left
Low inventory - Hurry! — Orders placed by 17:00 are usually dispatched the same working day
£74.29 inc. VAT
Pay in 3 interest-free payments with Klarna
Free UK mainland standard delivery 14-day returns

Need help choosing the right part? Call 01472 869 066

HONDA
CR-V III (RE_)
Description Cylinder Capacity Horse Power Year
2.4 i-VTEC 4WD (RE7) 2354 CCM 166 HP 09/2009 - 12/2012
2.4 4WD (RE4) 2354 CCM 168 HP 09/2006 - 06/2012
2.0 i-VTEC 4WD (RE5, RE2) 1997 CCM 150 HP 10/2006 - 06/2012
2.2 i-CTDi 4WD (RE6) 2204 CCM 140 HP 01/2007 - 02/2010
2.4 (RE3) 2354 CCM 170 HP 04/2007 - 12/2012
2.4 i-VTEC 4WD (RE4) 2354 CCM 160 HP 10/2006 - 10/2012
2.4 (RE3) 2354 CCM 168 HP 06/2006 - 06/2012
2.2 i-DTEC 4WD (RE6) 2199 CCM 150 HP 01/2007 - 06/2012
2.4 i-Vtec 4WD (RE4) 2354 CCM 170 HP 04/2007 - 12/2012
2.0 i-VTEC (RE5, RE1) 1997 CCM 150 HP 01/2007 - 06/2012
CR-V IV (RM_)
Description Cylinder Capacity Horse Power Year
2.4 AWD (RM4) 2354 CCM 190 HP 01/2012 - 12/2014

The NRF 35864 Condenser, air conditioning is a replacement heating, ventilation or air-conditioning component that supports refrigerant heat exchange or controlled airflow within the vehicle climate system. Its catalogue specification records with dryer and with seal ring, aluminium construction, 15.5 mm inlet diameter, and 10.1 mm outlet diameter. Match the reference, refrigerant-system specification, dimensions, connections, electrical details and vehicle application before fitting; refrigerant work must be carried out with approved recovery and charging equipment.

Function : Condenser, air conditioning
Supplementary Article/Supplementary Info 2 : with dryer
Material : Aluminium
Supplementary Article/Supplementary Info : with nitrogen filling
Core Length [mm] : 655
Core Width [mm] : 378
Core Depth [mm] : 16
Chemical Properties : Corrosion resistant
Inlet Diameter [mm] : 15.5
Outlet Diameter [mm] : 10.1
Supplementary Article/Supplementary Info 2 : with seal ring
  • Vendor NRF
  • SKU 35864
  • Barcode 8718042083432
  • HONDA : 80110SWAA01 80110SWNW01 80110SWWG01 80110SWWG02 80110SWYG01
  • BLUE PRINT : ADG080259
  • BORG & BECK : BDL7215
  • BOSCH : 1 986 AD2 346
  • DENSO : DCN40002
  • FEBI BILSTEIN : 101022
  • FEBI BILSTEIN : 105994
  • FEBI BILSTEIN : 36301
  • FIRST LINE : FDL7215
  • HELLA : 8FC 366 221-521
  • LEMFÖRDER : 36715 01
  • MAHLE : AC 719 000S
  • MAHLE : AC 811 000P
  • MAHLE : AC 811 000S
  • MEYLE : 016 060 0044/HD
  • MONROE : L23658
  • VALEO : 814232
  • VALEO : 822734
