NRF 35944 Condenser, air conditioning

SKU: 35944
Your selected vehicle
In stock
Order by 17:00 for same-day dispatch
£79.66 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

SUZUKI
SWIFT III (FZ, NZ)
Description Cylinder Capacity Horse Power Year
1.2 (AZH412, ZC72S) 1242 CCM 94 HP 10/2010 - 04/2017
1.2 4x4 (AZH412, ZD72S) 1242 CCM 94 HP 10/2010 - 04/2017
1.3 DDiS (AZG413D, ZC02S, ZC92S) 1248 CCM 75 HP 10/2010 - 04/2017
1.2 (AZG412, ZC72S) 1242 CCM 90 HP 10/2010 - 04/2017
1.2 4x4 (AZG412, ZD72S) 1242 CCM 90 HP 10/2010 - 04/2017
1.6 (AZG416, AZH416, RS416, ZC32S, ZA32S) 1586 CCM 136 HP 01/2012 - 04/2017

The NRF 35944 Condenser, air conditioning is a replacement heating, ventilation or air-conditioning component that supports refrigerant heat exchange or controlled airflow within the vehicle climate system. Its catalogue specification records with dryer and with seal ring, aluminium construction, 15.5 mm inlet diameter, and 10.1 mm outlet diameter. Match the reference, refrigerant-system specification, dimensions, connections, electrical details and vehicle application before fitting; refrigerant work must be carried out with approved recovery and charging equipment.

Function : Condenser, air conditioning
Supplementary Article/Supplementary Info 2 : with dryer
Material : Aluminium
Supplementary Article/Supplementary Info : with nitrogen filling
Core Length [mm] : 510
Core Width [mm] : 386
Core Depth [mm] : 12
Chemical Properties : Corrosion resistant
Inlet Diameter [mm] : 15.5
Outlet Diameter [mm] : 10.1
Supplementary Article/Supplementary Info 2 : with seal ring
for Model code : AZG412
Vehicle Identification Number (VIN) to : TSMNZA72S00534419
Vehicle Identification Number (VIN) to : TSMNZC72S00534399
Vehicle Identification Number (VIN) from : TSMNZA72S00534420
Vehicle Identification Number (VIN) from : TSMNZC72S00534400
for Model code : AZH412
  • Vendor NRF
  • SKU 35944
  • Barcode 8718042117120
  • SUZUKI : 9531068L00 9531068L10 9531068L11 9531071L00 9531071L01
  • APEC : ATH1007
  • BLUE PRINT : ADA109133
  • BLUE PRINT : ADG08525
  • BORG & BECK : BDL6610
  • BORG & BECK : BWP2377
  • BOSCH : 1 986 AD2 285
  • CORTECO : 49400050
  • DELPHI : CF20236
  • DENSO : DCN47007
  • FEBI BILSTEIN : 103077
  • FEBI BILSTEIN : 170321
  • FEBI BILSTEIN : 176935
  • FEBI BILSTEIN : 22481
  • FIRST LINE : FDL6610
  • FIRST LINE : FWP2377
  • HELLA : 8FC 366 222-321
  • MAHLE : AC 77 000S
  • MAHLE : MG 125
  • MEYLE : 316 060 0022/HD
  • MEYLE : 316 060 0078
  • MONROE : L11618
  • NAPA : NTH1007
  • VALEO : 814418
