Apec DSK2694 Brake Disc - 1
Apec DSK2694 Brake Disc - 1
APEC

Apec DSK2694 Brake Disc

SKU: DSK2694
Your selected vehicle
Only 3 left
Low inventory - Hurry! — Orders placed by 17:00 are usually dispatched the same working day
£48.48 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery on UK mainland orders. See our delivery information for coverage and current dispatch estimates.

HYUNDAI
SANTA FÉ II (CM)
Description Cylinder Capacity Horse Power Year
2.0 CRDi 1995 CCM 150 HP 12/2010 - 12/2012
2.0 CRDi 4x4 1995 CCM 150 HP 12/2010 - 12/2012
2.7 4x4 2656 CCM 170 HP 03/2006 - 12/2012
2.7 2656 CCM 170 HP 03/2006 - 12/2012
2.2 CRDi 2188 CCM 139 HP 03/2006 - 12/2012
2.2 CRDi 4x4 2188 CCM 139 HP 03/2006 - 12/2012
2.7 V6 GLS 2656 CCM 189 HP 03/2006 - 12/2009
2.7 V6 GLS 4x4 2656 CCM 189 HP 03/2006 - 12/2009
2.2 CRDi GLS 2188 CCM 150 HP 03/2006 - 12/2009
2.2 CRDi GLS 4x4 2188 CCM 150 HP 03/2006 - 12/2009
2.2 CRDi 2188 CCM 155 HP 03/2006 - 12/2009
2.2 CRDi 4x4 2188 CCM 155 HP 03/2006 - 12/2009
SANTA FÉ II SUV Van (CM)
Description Cylinder Capacity Horse Power Year
CRDi 2188 CCM 155 HP 09/2006 - 12/2011

The Apec DSK2694 Brake Disc is a replacement braking component that provides the rotating friction surface acted on by the pads or shoes. Its catalogue specification records solid disc construction, 302 mm outer diameter, 11 mm brake disc thickness, and 69 mm centering diameter. Match the reference, diameter, thickness, mounting pattern and vehicle application before fitting; braking components should be installed and checked by a competent person.

Function : Brake Disc
Brake Disc Type : solid
Outer Diameter [mm] : 302
Brake Disc Thickness [mm] : 11
Height [mm] : 71
Bolt Hole Circle Ø [mm] : 114
Centering Diameter [mm] : 69
Number of Holes : 5
Test Mark : 90R-02C01275/30201
  • Vendor APEC
  • SKU DSK2694
  • Barcode 5028906090951
  • HYUNDAI : 584112B000
  • APEC : SDK6602
  • BLUE PRINT : ADG043128
  • BORG & BECK : BBD4672
  • BOSCH : 0 986 479 509
  • BOSCH : 0 986 479 C15
  • DELPHI : BG4136
  • Fahren : FBD6602
  • FEBI BILSTEIN : 29351
  • HELLA : 8DD 355 119-051
  • MEYLE : 37-15 523 0013
  • MINTEX : MDC2012
  • NAPA : NBD5795
  • National : NBD1543
  • SKF : VKBD 91064 S2
  • TEXTAR : 92166103
  • TRW : DF6690
  • VALEO : 672961
