Apec DSK2774 Brake Disc - 1
Apec DSK2774 Brake Disc - 2
Apec DSK2774 Brake Disc - 1
Apec DSK2774 Brake Disc - 2
APEC

Apec DSK2774 Brake Disc

SKU: DSK2774
Your selected vehicle
In stock
Order by 17:00 for same-day dispatch
£21.34 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

TOYOTA
AURIS (_E15_)
Description Cylinder Capacity Horse Power Year
1.5 (NZE151_, NZE151N) 1497 CCM 110 HP 10/2006 - 08/2012
1.5 4WD (NZE154_, NZE154R) 1497 CCM 105 HP 10/2006 - 09/2012
1.6 (ZRE151_, ZRE151R) 1598 CCM 124 HP 03/2007 - 09/2012
1.4 (ZZE150_, ZZE150R) 1398 CCM 97 HP 03/2007 - 09/2012
1.8 (ZRE152) 1798 CCM 136 HP 10/2006 - 09/2012
1.33 Dual-VVTi (NRE150_, NRE150R) 1329 CCM 101 HP 05/2009 - 09/2012
1.6 (ZRE151_, ZRE151R) 1598 CCM 132 HP 05/2009 - 09/2012
1.8 Hybrid (ZWE150_, ZWE150R) 1798 CCM 136 HP 09/2010 - 09/2012
1.33 Dual-VVTi (NRE150_, NRE150R) 1329 CCM 99 HP 01/2010 - 09/2012

The Apec DSK2774 Brake Disc is a replacement braking component that provides the rotating friction surface acted on by the pads or shoes. Its catalogue specification records solid disc construction, 259 mm outer diameter, 9 mm brake disc thickness, and 15 mm wheel bolt bore diameter. Match the reference, diameter, thickness, mounting pattern and vehicle application before fitting; braking components should be installed and checked by a competent person.

Function : Brake Disc
Brake Disc Type : solid
Outer Diameter [mm] : 259
Brake Disc Thickness [mm] : 9
Height [mm] : 30
Bolt Hole Circle Ø [mm] : 114
Wheel Bolt Bore Diameter [mm] : 15
Centering Diameter [mm] : 62
Number of Holes : 5
Test Mark : 90R-02C01195/25349
  • Vendor APEC
  • SKU DSK2774
  • Barcode 5028906091750
  • TOYOTA : 4243102190 4243112260
  • APEC : SDK6634
  • BLUE PRINT : ADT343262
  • BORG & BECK : BBD4666
  • BOSCH : 0 986 479 418
  • BOSCH : 0 986 479 765
  • DELPHI : BG4233
  • Fahren : FBD6634
  • FEBI BILSTEIN : 108414
  • FEBI BILSTEIN : 108589
  • HELLA : 8DD 355 118-981
  • MEYLE : 30-15 523 0104
  • MEYLE : 30-15 523 0104/PD
  • MINTEX : MDC2048
  • NAPA : NBD5093
  • National : NBD1636
  • SKF : VKBD 90635 S2
  • TEXTAR : 92164103
  • TRW : DF4811
  • VALEO : 673044
