Apec DSK2870 Brake Disc

SKU: DSK2870

Your selected vehicle

In stock

Orders placed by 17:00 are usually dispatched the same working day

£37.35 inc. VAT

Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery on UK mainland orders. See our delivery information for coverage and current dispatch estimates.

SUZUKI

SWIFT III (FZ, NZ)

Description	Cylinder Capacity	Horse Power	Year
1.2 (AZH412, ZC72S)	1242 CCM	94 HP	10/2010 - 04/2017
1.2 4x4 (AZH412, ZD72S)	1242 CCM	94 HP	10/2010 - 04/2017
1.3 DDiS (AZG413D, ZC02S, ZC92S)	1248 CCM	75 HP	10/2010 - 04/2017
1.2 (AZG412, ZC72S)	1242 CCM	90 HP	10/2010 - 04/2017
1.2 4x4 (AZG412, ZD72S)	1242 CCM	90 HP	10/2010 - 04/2017
1.2 (AZH412, AZG412, ZC72S)	1242 CCM	91 HP	08/2012 - 04/2017
1.2 4WD (AZH412, AZG412, ZD72S)	1242 CCM	91 HP	08/2012 - 04/2017

The Apec DSK2870 Brake Disc is a replacement braking component that provides the rotating friction surface acted on by the pads or shoes. Its catalogue specification records solid disc construction, 259 mm outer diameter, 9 mm brake disc thickness, and 14 mm wheel bolt bore diameter. Match the reference, diameter, thickness, mounting pattern and vehicle application before fitting; braking components should be installed and checked by a competent person.

Function : Brake Disc

Brake Disc Type : solid

Outer Diameter [mm] : 259

Brake Disc Thickness [mm] : 9

Height [mm] : 43

Bolt Hole Circle Ø [mm] : 100

Wheel Bolt Bore Diameter [mm] : 14

Centering Diameter [mm] : 62

Number of Holes : 4

Test Mark : 90R-02C01195/25349

APEC : SDK6677
BLUE PRINT : ADK84339
BORG & BECK : BBD5209
BOSCH : 0 986 479 792
DELPHI : BG4345
Fahren : FBD6677
FEBI BILSTEIN : 108531
HELLA : 8DD 355 117-301
MEYLE : 33-15 523 0003/PD
MINTEX : MDC2267
NAPA : NBD5639
National : NBD1806
SKF : VKBD 90265 S2
TEXTAR : 92231403
