Apec DSK3064 Brake Disc

SKU: DSK3064
Your selected vehicle
In stock
Order by 17:00 for same-day dispatch
£72.74 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

BMW
5 (F10)
Description Cylinder Capacity Horse Power Year
525 d xDrive 1995 CCM 211 HP 09/2011 - 10/2016
525 d 1995 CCM 211 HP 09/2011 - 10/2016
520 i 1997 CCM 163 HP 09/2011 - 10/2016
520 i 1997 CCM 184 HP 09/2011 - 10/2016
528 i 1997 CCM 245 HP 09/2011 - 10/2016
528 i xDrive 1997 CCM 245 HP 09/2011 - 10/2016
530 i 2996 CCM 272 HP 05/2011 - 06/2013
525 d 1995 CCM 218 HP 09/2011 - 10/2016
525 d xDrive 1995 CCM 218 HP 09/2011 - 10/2016
5 Touring (F11)
Description Cylinder Capacity Horse Power Year
520 i 1997 CCM 184 HP 10/2010 - 02/2017
528 i 1997 CCM 245 HP 09/2011 - 02/2017
528 i xDrive 1997 CCM 245 HP 09/2011 - 02/2017
530 i 2996 CCM 272 HP 07/2011 - 06/2013
525 d 1995 CCM 218 HP 09/2011 - 02/2017
525 d xDrive 1995 CCM 218 HP 09/2011 - 02/2017
530 d 2993 CCM 258 HP 09/2011 - 02/2017
523 i 2996 CCM 204 HP 11/2009 - 08/2011
528 i 2996 CCM 258 HP 11/2009 - 08/2011

The Apec DSK3064 Brake Disc is a replacement braking component that provides the rotating friction surface acted on by the pads or shoes. Its catalogue specification records vented disc construction, 330 mm outer diameter, 20 mm brake disc thickness, and 17 mm wheel bolt bore diameter. Match the reference, diameter, thickness, mounting pattern and vehicle application before fitting; braking components should be installed and checked by a competent person.

Function : Brake Disc
Brake Disc Type : Vented
Outer Diameter [mm] : 330
Brake Disc Thickness [mm] : 20
Height [mm] : 64
Bolt Hole Circle Ø [mm] : 120
Wheel Bolt Bore Diameter [mm] : 17
Centering Diameter [mm] : 75
Number of Holes : 5
  • Vendor APEC
  • SKU DSK3064
  • Barcode 5028906093150
  • BMW : 34216775287 34216793127 34216898733
  • APEC : DSK3064B
  • APEC : SDK6782
  • BLUE PRINT : ADB114366
  • BORG & BECK : BBD6040S
  • BORG & BECK : BBD7026S
  • BOSCH : 0 986 479 D58
  • BOSCH : 0 986 479 E04
  • BREMBO : 09.C411.13
  • DELPHI : BG4664C
  • DELPHI : BG9421BC
  • Fahren : FBD6782
  • FEBI BILSTEIN : 104804
  • FTE : 9081303
  • HELLA : 8DD 355 120-671
  • NAPA : NBD5600
  • National : NBD1826
  • National : NBD1826B
  • SKF : VKBD 90102 V1
  • TEXTAR : 92265925
  • VALEO : 672784
