Apec DSK3074 Brake Disc - 1
Apec DSK3074 Brake Disc - 2
Apec DSK3074 Brake Disc - 1
Apec DSK3074 Brake Disc - 2
APEC

Apec DSK3074 Brake Disc

SKU: DSK3074
Your selected vehicle
In stock
Orders placed by 17:00 are usually dispatched the same working day
£36.91 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery on UK mainland orders. See our delivery information for coverage and current dispatch estimates.

HYUNDAI
KONA (OS, OSE, OSI)
Description Cylinder Capacity Horse Power Year
1.6 T-GDi 1591 CCM 177 HP 07/2017 - 12/2020
1.0 T-GDi 998 CCM 120 HP 07/2017 - 04/2023
1.0 T-GDi Hybrid 48V 998 CCM 120 HP 11/2020 - 04/2023
KIA
CARENS IV
Description Cylinder Capacity Horse Power Year
1.6 GDi 1591 CCM 135 HP 03/2013 - 08/2016
2.0 GDi 1999 CCM 177 HP From 03/2013
1.7 CRDi 1685 CCM 116 HP 03/2013 - 08/2016
1.7 CRDi 1685 CCM 136 HP 03/2013 - 08/2016
2.0 GDi 1999 CCM 166 HP 03/2013 - 08/2016
1.7 CRDi 1685 CCM 141 HP 07/2015 - 08/2016
2.0 MPI 1999 CCM 150 HP 03/2013 - 08/2016
2.0 GDi 1999 CCM 165 HP 06/2016 - 08/2016
SOUL II (PS)
Description Cylinder Capacity Horse Power Year
1.6 TGDI 1591 CCM 204 HP 11/2016 - 12/2018
SOUL III (SK3)
Description Cylinder Capacity Horse Power Year
1.6 T-GDI 1591 CCM 200 HP From 01/2019

The Apec DSK3074 Brake Disc is a replacement braking component that provides the rotating friction surface acted on by the pads or shoes. Its catalogue specification records solid disc construction, 284 mm outer diameter, 10 mm brake disc thickness, and 12 mm wheel bolt bore diameter. Match the reference, diameter, thickness, mounting pattern and vehicle application before fitting; braking components should be installed and checked by a competent person.

Function : Brake Disc
Brake Disc Type : solid
Outer Diameter [mm] : 284
Brake Disc Thickness [mm] : 10
Height [mm] : 45
Bolt Hole Circle Ø [mm] : 114
Wheel Bolt Bore Diameter [mm] : 12
Centering Diameter [mm] : 76
Number of Holes : 5
Test Mark : 90R-02C0270/0007
  • Vendor APEC
  • SKU DSK3074
  • Barcode 5028906093242
  • KIA : 58411A4000 58411B2500
  • APEC : SDK6787
  • BLUE PRINT : ADG043210
  • BORG & BECK : BBD5398
  • BOSCH : 0 986 479 C39
  • BOSCH : 0 986 479 G28
  • DELPHI : BG4708C
  • Fahren : FBD6787
  • FEBI BILSTEIN : 108550
  • HELLA : 8DD 355 120-471
  • MEYLE : 28-15 523 0026/PD
  • MINTEX : MDC2606
  • NAPA : NBD5659
  • National : NBD1911
  • TEXTAR : 92267803
  • VALEO : 673001
