Apec DSK3136 Brake Disc - 1
Apec DSK3136 Brake Disc - 1
APEC

Apec DSK3136 Brake Disc

SKU: DSK3136
Your selected vehicle
Only 4 left
Low inventory - Hurry! — Order by 17:00 for same-day dispatch
£77.58 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

BMW
5 Gran Turismo (F07)
Description Cylinder Capacity Horse Power Year
550 i 4395 CCM 408 HP 08/2009 - 06/2012
550 i xDrive 4395 CCM 408 HP 06/2010 - 06/2012
550 i 4395 CCM 449 HP 07/2012 - 02/2017
550 i xDrive 4395 CCM 449 HP 07/2012 - 02/2017
5 Touring (F11)
Description Cylinder Capacity Horse Power Year
550 i 4395 CCM 408 HP 09/2010 - 06/2013
6 Convertible (F12)
Description Cylinder Capacity Horse Power Year
650 i 4395 CCM 408 HP 12/2010 - 06/2012
650 i xDrive 4395 CCM 407 HP 09/2011 - 06/2012
650 i xDrive 4395 CCM 449 HP 07/2012 - 06/2018
650 i 4395 CCM 449 HP 07/2012 - 06/2018
650 i 4395 CCM 405 HP 09/2011 - 12/2012
6 Coupe (F13)
Description Cylinder Capacity Horse Power Year
650 i 4395 CCM 449 HP 07/2012 - 10/2017
7 (F01, F02, F03, F04)
Description Cylinder Capacity Horse Power Year
750 i, Li 4395 CCM 408 HP 09/2008 - 06/2012
750 i, Li xDrive 4395 CCM 408 HP 09/2009 - 06/2012

The Apec DSK3136 Brake Disc is a replacement braking component that provides the rotating friction surface acted on by the pads or shoes. Its catalogue specification records vented disc construction, 374 mm outer diameter, 36 mm brake disc thickness, and 75 mm centering diameter. Match the reference, diameter, thickness, mounting pattern and vehicle application before fitting; braking components should be installed and checked by a competent person.

Function : Brake Disc
Brake Disc Type : Vented
Outer Diameter [mm] : 374
Brake Disc Thickness [mm] : 36
Height [mm] : 66
Bolt Hole Circle Ø [mm] : 120
Centering Diameter [mm] : 75
Number of Holes : 5
  • Vendor APEC
  • SKU DSK3136
  • Barcode 5028906097851
  • BMW : 34106894384 34116785676
  • BLUE PRINT : ADB1143118
  • BORG & BECK : BBD6179S
  • BORG & BECK : BBD7028S
  • BOSCH : 0 986 479 E27
  • BREMBO : 09.C408.13
  • DELPHI : BG9161BC
  • DELPHI : BG9161C
  • FEBI BILSTEIN : 108212
  • HELLA : 8DD 355 120-691
  • SKF : VKBD 80757 V1
  • TEXTAR : 92266125
