Apec DSK3314 Brake Disc - 1
Apec DSK3314 Brake Disc - 2
Apec DSK3314 Brake Disc - 1
Apec DSK3314 Brake Disc - 2
APEC

Apec DSK3314 Brake Disc

SKU: DSK3314
Your selected vehicle
Only 2 left
Low inventory - Hurry! — Orders placed by 17:00 are usually dispatched the same working day
£61.14 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery on UK mainland orders. See our delivery information for coverage and current dispatch estimates.

OPEL
ASTRA J Coupe
Description Cylinder Capacity Horse Power Year
2.0 OPC Turbo (08) 1998 CCM 280 HP 04/2012 - 04/2018
VAUXHALL
ASTRA Mk VI (J) GTC (P10)
Description Cylinder Capacity Horse Power Year
2.0 VXR 1998 CCM 280 HP 04/2012 - 10/2018

The Apec DSK3314 Brake Disc is a replacement braking component that provides the rotating friction surface acted on by the pads or shoes. Its catalogue specification records perforated/vented disc construction, 315 mm outer diameter, 23 mm brake disc thickness, and 71 mm centering diameter. Match the reference, diameter, thickness, mounting pattern and vehicle application before fitting; braking components should be installed and checked by a competent person.

Function : Brake Disc
Brake Disc Type : perforated/vented
Outer Diameter [mm] : 315
Brake Disc Thickness [mm] : 23
Height [mm] : 45
Bolt Hole Circle Ø [mm] : 115
Centering Diameter [mm] : 71
Number of Holes : 5
  • Vendor APEC
  • SKU DSK3314
  • Barcode 5028906117269
  • OPEL : 569089 569094
  • VAUXHALL : 13371163 13429575
  • BLUE PRINT : ADW194345
  • BORG & BECK : BBD6114S
  • DELPHI : BG4923C
  • FEBI BILSTEIN : 108196
  • HELLA : 8DD 355 126-391
  • MINTEX : MDC2790C
  • National : NBD2202
  • TEXTAR : 92290003
