Apec DSK3378 Brake Disc - 1
Apec DSK3378 Brake Disc - 2
Apec DSK3378 Brake Disc - 1
Apec DSK3378 Brake Disc - 2
APEC

Apec DSK3378 Brake Disc

SKU: DSK3378
Your selected vehicle
In stock
Orders placed by 17:00 are usually dispatched the same working day
£29.09 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery on UK mainland orders. See our delivery information for coverage and current dispatch estimates.

SUZUKI
BALENO (FW, EW)
Description Cylinder Capacity Horse Power Year
1.0 (A1K310) 998 CCM 111 HP From 02/2016
1.2 (A1K412) 1242 CCM 90 HP From 02/2016
1.2 Hybrid (A1K412) 1242 CCM 90 HP From 02/2016
SWIFT V (AZ)
Description Cylinder Capacity Horse Power Year
1.0 (A2L310) 998 CCM 111 HP From 04/2017
1.0 SHVS (A2L310) 998 CCM 111 HP From 04/2017
1.2 (A2L412, ZC83S) 1242 CCM 90 HP From 04/2017
1.2 SHVS (A2L412) 1242 CCM 90 HP From 04/2017
1.2 SHVS AllGrip (A2L412) 1242 CCM 90 HP From 04/2017
1.2 AllGrip (A2L412) 1242 CCM 90 HP From 04/2017
1.2 SHVS AllGrip (ZD53S) 1242 CCM 91 HP From 01/2017
1.2 Hybrid (Mild Hybrid) (A2L412) 1197 CCM 83 HP From 06/2020
1.2 Hybrid (Mild Hybrid) AllGrip (A2L412) 1197 CCM 83 HP From 06/2020
SWIFT VI (ZD_, ZC_)
Description Cylinder Capacity Horse Power Year
1.2 VVT Hybrid (ZCEDS, AOL312) 1197 CCM 83 HP From 12/2023
1.2 VVT Hybrid AllGrip (ZDEDS, AOL312) 1197 CCM 83 HP From 12/2023

The Apec DSK3378 Brake Disc is a replacement braking component that provides the rotating friction surface acted on by the pads or shoes. Its catalogue specification records vented disc construction, 252 mm outer diameter, 20 mm brake disc thickness, and 60 mm centering diameter. Match the reference, diameter, thickness, mounting pattern and vehicle application before fitting; braking components should be installed and checked by a competent person.

Function : Brake Disc
Brake Disc Type : Vented
Outer Diameter [mm] : 252
Brake Disc Thickness [mm] : 20
Height [mm] : 40
Bolt Hole Circle Ø [mm] : 100
Centering Diameter [mm] : 60
Number of Holes : 4
Machining : High-carbon
Test Mark : 90R-02C 01275/37305
  • Vendor APEC
  • SKU DSK3378
  • Barcode 5028906118648
  • SUZUKI : 5531152R50 5531152R50000 55311M69P10
  • APEC : SDK6944
  • BLUE PRINT : ADK84349
  • BLUE PRINT : ADK84350
  • BORG & BECK : BBD5520
  • BOSCH : 0 986 479 F37
  • DELPHI : BG4971C
  • Fahren : FBD6944
  • FEBI BILSTEIN : 170724
  • FEBI BILSTEIN : 170725
  • HELLA : 8DD 355 132-051
  • MEYLE : 33-15 521 0022/PD
  • MINTEX : MDC2869C
  • NAPA : NBD5158
  • National : NBD2033
  • TEXTAR : 92303703
