APEC

Apec DSK3443 Brake Disc

SKU: DSK3443
Your selected vehicle
In stock
Orders placed by 17:00 are usually dispatched the same working day
£38.42 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery on UK mainland orders. See our delivery information for coverage and current dispatch estimates.

VOLVO
XC40 (536)
Description Cylinder Capacity Horse Power Year
T3 1477 CCM 156 HP 03/2018 - 03/2019
D3 1969 CCM 150 HP 09/2018 - 09/2021
D3 AWD 1969 CCM 150 HP 09/2018 - 09/2021
T3 1477 CCM 163 HP 03/2019 - 12/2022
T2 1477 CCM 129 HP From 06/2019

The Apec DSK3443 Brake Disc is a replacement braking component that provides the rotating friction surface acted on by the pads or shoes. Its catalogue specification records solid disc construction, 280 mm outer diameter, 12 mm brake disc thickness, and 64 mm centering diameter. Match the reference, diameter, thickness, mounting pattern and vehicle application before fitting; braking components should be installed and checked by a competent person.

Function : Brake Disc
Brake Disc Type : solid
Outer Diameter [mm] : 280
Brake Disc Thickness [mm] : 12
Height [mm] : 37
Bolt Hole Circle Ø [mm] : 108
Centering Diameter [mm] : 64
Number of Holes : 5
Machining : High-carbon
Test Mark : 90R-02C0270/0251
  • Vendor APEC
  • SKU DSK3443
  • Barcode 5028906142575
  • VOLVO : 31471476 32300124 VOL241
  • BLUE PRINT : ADF124373
  • BORG & BECK : BBD5624
  • BOSCH : 0 986 479 F41
  • DELPHI : BG5069C
  • FEBI BILSTEIN : 107517
  • HELLA : 8DD 355 133-411
  • MEYLE : 515 523 0023/PD
  • MINTEX : MDC2983C
  • National : NBD2115
  • TEXTAR : 92323803
  • VALEO : 673382
