Apec DSK4223 Brake Disc - 1
Apec DSK4223 Brake Disc - 1
APEC

Apec DSK4223 Brake Disc

SKU: DSK4223
Your selected vehicle
In stock
Orders placed by 17:00 are usually dispatched the same working day
£52.63 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery on UK mainland orders. See our delivery information for coverage and current dispatch estimates.

TESLA
MODEL Y
Description Cylinder Capacity Horse Power Year
EV Performance All-wheel Drive 462 HP 03/2019 - 01/2025
EV All-wheel Drive 450 HP 07/2021 - 01/2025
EV Performance All-wheel Drive 534 HP 09/2021 - 01/2025
EV Performance All-wheel Drive 436 HP 09/2021 - 01/2025

The Apec DSK4223 Brake Disc is a replacement braking component that provides the rotating friction surface acted on by the pads or shoes. Its catalogue specification records vented disc construction, 335 mm outer diameter, 22 mm brake disc thickness, and 70 mm centering diameter. Match the reference, diameter, thickness, mounting pattern and vehicle application before fitting; braking components should be installed and checked by a competent person.

Function : Brake Disc
Brake Disc Type : Vented
Outer Diameter [mm] : 335
Brake Disc Thickness [mm] : 22
Supplementary Article/Supplementary Info 2 : without ABS sensor ring
Supplementary Article/Supplementary Info 2 : without wheel bearing
Height [mm] : 47
Bolt Hole Circle Ø [mm] : 114
Centering Diameter [mm] : 70
Number of Holes : 5
Test Mark : 90R-02C01514/55718
  • Vendor APEC
  • SKU DSK4223
  • Barcode 5028906260293
  • TESLA : 118863699A
  • MINTEX : MDC3222C
  • TEXTAR : 92352003
