Apec DSK682 Brake Disc - 1
Apec DSK682 Brake Disc - 1
APEC

Apec DSK682 Brake Disc

SKU: DSK682
Your selected vehicle
Only 5 left
Low inventory - Hurry! — Orders placed by 17:00 are usually dispatched the same working day
£33.55 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery on UK mainland orders. See our delivery information for coverage and current dispatch estimates.

MERCEDES-BENZ
V-CLASS (638/2)
Description Cylinder Capacity Horse Power Year
V 230 (638.234, 638.294) 2295 CCM 143 HP 10/1996 - 07/2003
V 280 (638.244, 638.294) 2792 CCM 174 HP 08/1997 - 07/2003
V 220 CDI (638.294) 2148 CCM 122 HP 03/1999 - 07/2003
VITO Bus (W638)
Description Cylinder Capacity Horse Power Year
108 D 2.3 (638.164) 2299 CCM 79 HP 02/1996 - 07/2003
113 2.0 (638.114, 638.194) 1998 CCM 129 HP 02/1996 - 07/2003
108 CDI 2.2 (638.194) 2148 CCM 82 HP 03/1999 - 07/2003
110 CDI 2.2 (638.194) 2148 CCM 102 HP 03/1999 - 07/2003
112 CDI 2.2 (638.194) 2148 CCM 122 HP 03/1999 - 07/2003
VITO Van (W638)
Description Cylinder Capacity Horse Power Year
108 D 2.3 (638.064, 638.068) 2299 CCM 79 HP 03/1997 - 07/2003
113 2.0 (638.014, 638.094) 1998 CCM 129 HP 03/1997 - 07/2003
108 CDI 2.2 (638.094) 2148 CCM 82 HP 03/1999 - 07/2003
110 CDI 2.2 (638.094) 2148 CCM 102 HP 03/1999 - 07/2003
112 CDI 2.2 (638.094) 2148 CCM 122 HP 03/1999 - 07/2003

The Apec DSK682 Brake Disc is a replacement braking component that provides the rotating friction surface acted on by the pads or shoes. Its catalogue specification records vented disc construction, 276 mm outer diameter, 22 mm brake disc thickness, and 67 mm centering diameter. Match the reference, diameter, thickness, mounting pattern and vehicle application before fitting; braking components should be installed and checked by a competent person.

Function : Brake Disc
Brake Disc Type : Vented
Outer Diameter [mm] : 276
Brake Disc Thickness [mm] : 22
Height [mm] : 60
Bolt Hole Circle Ø [mm] : 112
Centering Diameter [mm] : 67
Number of Holes : 5
Test Mark : 90R-02C0349/0052
  • Vendor APEC
  • SKU DSK682
  • Barcode 5028906075835
  • MERCEDES-BENZ : 6384210112 A6384210112
  • APEC : SDK6232
  • BLUE PRINT : ADU174369
  • BORG & BECK : BBD4072
  • BOSCH : 0 986 479 B53
  • BOSCH : 0 986 479 R95
  • BREMBO : 09.6983.10
  • DELPHI : BG3296
  • FEBI BILSTEIN : 10642
  • HELLA : 8DD 355 104-521
  • MEYLE : 015 521 2034
  • MINTEX : MDC1038
  • National : NBD865
  • SKF : VKBD 80239 V2
  • TEXTAR : 92074403
  • TRW : DF2797
  • VALEO : 186551
  • VALEO : 673482
