Apec DSK810 Brake Disc - 1
Apec DSK810 Brake Disc - 1
APEC

Apec DSK810 Brake Disc

SKU: DSK810
Your selected vehicle
Only 4 left
Low inventory - Hurry! — Orders placed by 17:00 are usually dispatched the same working day
£37.22 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery on UK mainland orders. See our delivery information for coverage and current dispatch estimates.

HONDA
CR-V I (RD)
Description Cylinder Capacity Horse Power Year
2.0 16V 4WD (RD1, RD3) 1973 CCM 128 HP 10/1995 - 12/2001
2.0 16V 4WD (RD1, RD3) 1973 CCM 147 HP 01/1999 - 02/2002
HR-V (GH_)
Description Cylinder Capacity Horse Power Year
1.6 16V 4WD (GH2, GH4) 1590 CCM 105 HP From 03/1999
1.6 16V 4WD (GH2, GH4) 1590 CCM 124 HP 10/1999 - 09/2005
1.6 16V (GH1, GH3) 1590 CCM 105 HP From 03/1999
INTEGRA Coupe (DC)
Description Cylinder Capacity Horse Power Year
1.8 Type-R (DC2) 1797 CCM 190 HP 11/1997 - 10/2001
INTEGRA Saloon (DB6, DB7, DB8, DB9)
Description Cylinder Capacity Horse Power Year
1.8 VTEC (DB8) 1797 CCM 180 HP 09/1993 - 08/2001
LEGEND Mk III (KA)
Description Cylinder Capacity Horse Power Year
3.5 i 24V (KA9) 3474 CCM 205 HP 02/1996 - 10/1997
ODYSSEY (RA_)
Description Cylinder Capacity Horse Power Year
2.3 4x4 (RA4) 2254 CCM 150 HP 10/1997 - 12/1999
2.3 (RA3, RA6) 2254 CCM 150 HP 10/1997 - 12/1999
2.2 (RA1) 2156 CCM 141 HP 10/1995 - 12/1997
PRELUDE Mk V (BB_)
Description Cylinder Capacity Horse Power Year
2.2 16V (BB6, BB8) 2156 CCM 185 HP 10/1996 - 10/2000
2.2 16V (BB6, BB8) 2156 CCM 200 HP 10/1996 - 12/2001
SHUTTLE (RA)
Description Cylinder Capacity Horse Power Year
2.2 16V (RA1) 2156 CCM 150 HP 10/1994 - 02/1998
2.3 16V (RA3, RA5) 2254 CCM 150 HP 10/1997 - 06/2004
3.0 (RA8) 2997 CCM 209 HP 10/1997 - 06/2004
3.0 4x4 (RA9) 2997 CCM 209 HP 10/1997 - 06/2002
STEPWGN (E-RF_, GF-RF_)
Description Cylinder Capacity Horse Power Year
2.0 (RF1) 1972 CCM 135 HP 05/1996 - 09/2000

The Apec DSK810 Brake Disc is a replacement braking component that provides the rotating friction surface acted on by the pads or shoes. Its catalogue specification records vented disc construction, 282 mm outer diameter, 23 mm brake disc thickness, and 70 mm centering diameter. Match the reference, diameter, thickness, mounting pattern and vehicle application before fitting; braking components should be installed and checked by a competent person.

Function : Brake Disc
Brake Disc Type : Vented
Outer Diameter [mm] : 282
Brake Disc Thickness [mm] : 23
Height [mm] : 47
Bolt Hole Circle Ø [mm] : 114
Centering Diameter [mm] : 70
Number of Holes : 5
Test Mark : 90R-02C0349/1357
  • Vendor APEC
  • SKU DSK810
  • Barcode 5028906077112
  • HONDA : 45251S2HN00 45251SP0000 45251SZ3000 45251SZ3E00
  • APEC : SDK6237
  • BLUE PRINT : ADH24341
  • BORG & BECK : BBD4090
  • BOSCH : 0 986 478 667
  • BREMBO : 09.6893.11
  • BREMBO : 09.6893.14
  • DELPHI : BG3060
  • DELPHI : BG3061
  • FEBI BILSTEIN : 108428
  • HELLA : 8DD 355 107-131
  • MEYLE : 31-15 521 0016
  • MINTEX : MDC998
  • National : NBD817
  • SKF : VKBD 80429 V2
  • TEXTAR : 92101000
  • TRW : DF4028
  • VALEO : 186778
  • VALEO : 673278
