Apec LCA102 Brake Caliper

SKU: LCA102

Your selected vehicle

Out of stock

Out of Stock

£64.12 inc. VAT

Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

FORD

TRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _)

Description	Cylinder Capacity	Horse Power	Year
2.2 TDCi	2198 CCM	100 HP	10/2011 - 08/2014
2.2 TDCi	2198 CCM	125 HP	10/2011 - 08/2014
2.2 TDCi	2198 CCM	110 HP	04/2006 - 08/2014
2.2 TDCi	2198 CCM	85 HP	04/2006 - 08/2014
2.2 TDCi	2198 CCM	130 HP	04/2006 - 08/2014

TRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _)

Description	Cylinder Capacity	Horse Power	Year
2.2 TDCi	2198 CCM	100 HP	10/2011 - 08/2014
2.2 TDCi	2198 CCM	125 HP	10/2011 - 08/2014
2.2 TDCi	2198 CCM	85 HP	04/2006 - 08/2014
2.2 TDCi	2198 CCM	110 HP	04/2006 - 08/2014
2.2 TDCi	2198 CCM	130 HP	04/2006 - 08/2014
2.2 TDCi	2198 CCM	140 HP	10/2007 - 08/2014
2.2 TDCi	2198 CCM	115 HP	10/2008 - 08/2014
2.2 TDCi RWD	2198 CCM	135 HP	09/2011 - 08/2014

TRANSIT Van (FA_ _)

Description	Cylinder Capacity	Horse Power	Year
2.2 TDCi	2198 CCM	100 HP	10/2011 - 08/2014
2.2 TDCi	2198 CCM	125 HP	10/2011 - 08/2014
2.2 TDCi	2198 CCM	110 HP	04/2006 - 08/2014
2.2 TDCi	2198 CCM	130 HP	04/2006 - 08/2014
2.2 TDCi	2198 CCM	85 HP	04/2006 - 08/2014

TRANSIT TOURNEO Bus

Description	Cylinder Capacity	Horse Power	Year
2.2 TDCi	2198 CCM	110 HP	07/2006 - 08/2014
2.2 TDCi	2198 CCM	131 HP	07/2006 - 08/2014
2.2 TDCi	2198 CCM	140 HP	10/2007 - 08/2014
2.2 TDCi	2198 CCM	115 HP	10/2008 - 08/2014
2.2	2198 CCM	125 HP	10/2011 - 08/2014

The Apec LCA102 Brake Caliper is a replacement braking-system component that forms part of the mechanism that applies or releases braking force. Its catalogue specification records in front of axle fitting position, Bosch brake-system specification, vented disc construction, and brake Caliper (2 pistons). Confirm the reference, brake-system specification, fitting position, connections and vehicle application before fitting; installation and bleeding should follow the vehicle manufacturer's procedure.

Function : Brake Caliper

Fitting Position : in front of axle

Brake System : Bosch

Brake Disc Type : Vented

Brake Caliper Type : Brake Caliper (2 pistons)

Piston Diameter 1 [mm] : 48

for brake disc thickness [mm] : 28

for brake disc diameter [mm] : 280

Material : Grey Cast Iron

Article number of recommended accessories : BBS6

Article number of recommended accessories : BSC1
