Apec LCA687 Brake Caliper

SKU: LCA687

Your selected vehicle

Only 1 left

Low inventory - Hurry! — Order by 17:00 for same-day dispatch

£92.78 inc. VAT

Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

TOYOTA

RAV 4 III (_A3_)

Description	Cylinder Capacity	Horse Power	Year
2.0 4WD (ACA30_, ACA30R)	1998 CCM	152 HP	02/2006 - 06/2013
2.2 D 4WD (ALA30_, ALA30R)	2231 CCM	136 HP	02/2006 - 12/2012
2.2 D 4WD (ALA30_, ALA30R)	2231 CCM	177 HP	02/2006 - 06/2013
2.0 (ZSA35_, ZSA35R)	1987 CCM	158 HP	12/2008 - 06/2013
2.0 4WD (ZSA30_, ZSA30R)	1987 CCM	158 HP	12/2008 - 06/2013
2.2 D 4WD (ALA30_, ALA30R)	2231 CCM	150 HP	12/2008 - 06/2013
2.2 D (ALA35_)	2231 CCM	150 HP	12/2008 - 06/2013

RAV 4 IV (_A4_)

Description	Cylinder Capacity	Horse Power	Year
2.0 D (ALA40_, ALA40R)	1998 CCM	124 HP	12/2012 - 11/2018
2.0 4WD (ZSA44_, ZSA44R)	1987 CCM	151 HP	12/2012 - 10/2018
2.2 D 4WD (ALA49)	2231 CCM	150 HP	12/2012 - 09/2019
2.0 D 4WD (ALA41_)	1998 CCM	124 HP	01/2013 - 11/2018

The Apec LCA687 Brake Caliper is a replacement braking-system component that forms part of the mechanism that applies or releases braking force. Its catalogue specification records behind the axle fitting position, Advics brake-system specification, solid disc construction, and brake Caliper (1 piston). Confirm the reference, brake-system specification, fitting position, connections and vehicle application before fitting; installation and bleeding should follow the vehicle manufacturer's procedure.

Function : Brake Caliper

Fitting Position : behind the axle

Brake System : Advics

Brake Disc Type : solid

Brake Caliper Type : Brake Caliper (1 piston)

Piston Diameter 1 [mm] : 38

for brake disc thickness [mm] : 12

for brake disc diameter [mm] : 281

Material : Aluminium

Article number of recommended accessories : BBS8

Article number of recommended accessories : BSC1
