Blue Print ADB112230 Air Filter - 1
Blue Print ADB112230 Air Filter - 2
Blue Print ADB112230 Air Filter video
Blue Print ADB112230 Air Filter video
Blue Print ADB112230 Air Filter video
Blue Print ADB112230 Air Filter - 1
Blue Print ADB112230 Air Filter - 2
Blue Print ADB112230 Air Filter video
Blue Print ADB112230 Air Filter video
Blue Print ADB112230 Air Filter video
BLUE PRINT

Blue Print ADB112230 Air Filter

SKU: 100597
Your selected vehicle
Out of stock
Out of Stock
£22.91 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery on UK mainland orders. See our delivery information for coverage and current dispatch estimates.

BMW
5 (E34)
Description Cylinder Capacity Horse Power Year
530 i V8 2997 CCM 218 HP 09/1992 - 12/1995
540 i V8 3982 CCM 286 HP 09/1992 - 12/1995
5 Touring (E34)
Description Cylinder Capacity Horse Power Year
530 i 2997 CCM 218 HP 09/1992 - 07/1996
540 i 3982 CCM 286 HP 09/1993 - 07/1996
5 (E39)
Description Cylinder Capacity Horse Power Year
540 i 4398 CCM 286 HP 03/1996 - 06/2003
535 i 3498 CCM 235 HP 06/1996 - 08/1998
M5 4941 CCM 400 HP 10/1998 - 06/2003
535 i 3498 CCM 245 HP 09/1998 - 06/2003
5 Touring (E39)
Description Cylinder Capacity Horse Power Year
540 i 4398 CCM 286 HP 04/1997 - 12/2003
7 (E32)
Description Cylinder Capacity Horse Power Year
730 i, iL V8 2997 CCM 218 HP 04/1992 - 09/1994
740 i, iL V8 3982 CCM 286 HP 05/1992 - 03/1994
7 (E38)
Description Cylinder Capacity Horse Power Year
730 i, iL 2997 CCM 211 HP 10/1994 - 11/2001
730 i, iL 2997 CCM 218 HP 03/1994 - 02/1996
740 i, iL 3982 CCM 286 HP 03/1994 - 02/1996
740 i, iL 4398 CCM 286 HP 02/1996 - 07/2001
735 i, iL 3498 CCM 235 HP 03/1996 - 08/1998
8 (E31)
Description Cylinder Capacity Horse Power Year
840 i 3982 CCM 286 HP 03/1993 - 02/1996
840 Ci 4398 CCM 286 HP 03/1996 - 06/1999
X5 (E53)
Description Cylinder Capacity Horse Power Year
4.4 i 4398 CCM 286 HP 01/2000 - 09/2003
4.6 is 4619 CCM 347 HP 10/2001 - 09/2003
4.4 i 4398 CCM 320 HP 10/2003 - 10/2006
4.8 is 4799 CCM 360 HP 04/2004 - 09/2006

The Blue Print ADB112230 Air Filter is a replacement filtration component that helps retain contamination while allowing the relevant air, oil, fuel or cabin-air flow. Its catalogue specification records filter Insert filter design, 250 mm length, 210 mm width, and 57 mm height. Use Blue print reference 100597 when cross-checking the part. Compare the reference, filter design, dimensions and vehicle application data below with the removed part before ordering, because filter formats can vary within the same model range.

Function : Air Filter
Filter type : Filter Insert
Length [mm] : 250
Width [mm] : 210
Height [mm] : 57
  • Vendor BLUE PRINT
  • SKU 100597
  • BMW : 13 71 1 736 675 13 72 1 247 280 13 72 1 433 933 13 72 1 702 158 13 72 1 733 562 13 72 1 733 581 13 72 1 736 675 13 72 1 747 280
  • BLUE PRINT : ADA103001
  • FEBI BILSTEIN : 1003217
  • HELLA : 8FK 366 201-061
  • KYB : 365006
  • KYB : 665008
  • LUCAS : ACP216
  • MAHLE : ACP 855 000P
  • MAHLE : ACP 855 000S
