BREMBO

Brembo 09.A738.11 Brake Disc

5.0/5 60 AutoMotoPart customer reviews Verified reviews across our products & service
SKU: 09.A738.11

Check product compatibility

Enter your registration or select your vehicle to check this product fits.

Only 2 left
Low inventory - Hurry! — Orders placed by 17:00 are usually dispatched the same working day
£94.44 inc. VAT
Pay in 3 interest-free payments with Klarna
Free UK mainland standard delivery 14-day returns

Need help choosing the right part? Call 01472 869 066

CITROËN
C-CROSSER (VU_, VV_)
Description Cylinder Capacity Horse Power Year
2.2 HDi 2179 CCM 156 HP 02/2007 - 12/2012
2.4 16V 2360 CCM 170 HP 08/2008 - 12/2012
C-CROSSER Van (VU_)
Description Cylinder Capacity Horse Power Year
2.2 HDi (VU4HNH) 2179 CCM 156 HP 06/2007 - 12/2012
C-CROSSER ENTERPRISE (VU_, VV_)
Description Cylinder Capacity Horse Power Year
2.4 16V 2360 CCM 170 HP From 01/2009
2.2 HDi 2179 CCM 156 HP From 01/2009
MITSUBISHI
GALANT / ASPIRE Mk VI (EA_)
Description Cylinder Capacity Horse Power Year
2.5 V6 24V (EC5A) 2498 CCM 280 HP 09/1996 - 10/2002
LANCER Mk IV (C6_A, C7_A)
Description Cylinder Capacity Horse Power Year
EVO IV (CN9A) 1997 CCM 280 HP 08/1996 - 12/1997
LANCER Mk V (CB_A, CD_A, CE_A)
Description Cylinder Capacity Horse Power Year
EVO I (CD9A) 1997 CCM 250 HP 10/1992 - 12/1993
LANCER VIII Sportback (CX_A)
Description Cylinder Capacity Horse Power Year
2.0 Ralliart 4WD (CX4A) 1998 CCM 241 HP From 10/2008
OUTLANDER I (CU_W)
Description Cylinder Capacity Horse Power Year
2.0 4WD (CU2W) 1997 CCM 136 HP 05/2003 - 10/2006
2.4 4WD (CU5W) 2378 CCM 160 HP 11/2003 - 09/2007
2.0 Turbo 4WD (CU2W) 1997 CCM 201 HP 04/2004 - 10/2006
2.0 Turbo-R 4WD (CU2W) 1997 CCM 241 HP 01/2002 - 10/2006
2.4 4WD (CU4W) 2351 CCM 139 HP 05/2003 - 10/2006
2.4 4WD (CU5W) 2378 CCM 162 HP 05/2003 - 09/2007
2.0 (CU2W) 1997 CCM 136 HP 05/2003 - 10/2006
2.4 HDD Mivec (CU5W) 2378 CCM 160 HP 03/2001 - 12/2006
OUTLANDER II (CW_W)
Description Cylinder Capacity Horse Power Year
2.0 (CW4W) 1998 CCM 147 HP 11/2006 - 11/2012
2.2 DI-D 2268 CCM 177 HP 11/2006 - 11/2012
2.2 DI-D 4WD 2268 CCM 177 HP 11/2006 - 11/2012
2.2 DI-D 4WD 2268 CCM 140 HP 09/2010 - 11/2012
2.0 4WD 1998 CCM 147 HP 11/2006 - 11/2012
2.4 Flex 4WD 2360 CCM 170 HP 09/2007 - 11/2012
2.0 DI-D (CW8W) 1968 CCM 140 HP 02/2007 - 11/2012
2.4 4WD (CW5W) 2360 CCM 170 HP 09/2007 - 11/2012
2.2 DI-D 4WD 2179 CCM 156 HP 08/2007 - 11/2012
2.4 (CW5W) 2360 CCM 170 HP 11/2006 - 11/2012
OUTLANDER II Van (CW_W)
Description Cylinder Capacity Horse Power Year
Di-D 4WD (CW8W) 1968 CCM 140 HP 12/2006 - 06/2010
Di-D 4WD (CW1W) 2268 CCM 177 HP 09/2010 - 12/2012
OUTLANDER III (GG_W, GF_W, ZJ, ZL, ZK)
Description Cylinder Capacity Horse Power Year
2.0 (GF2W) 1998 CCM 146 HP 10/2012 - 12/2022
2.0 4WD (GF7W, GF2W) 1998 CCM 146 HP 10/2012 - 12/2022
2.0 (GF7W) 1998 CCM 150 HP 08/2012 - 12/2022
2.0 4WD (GF7W) 1998 CCM 150 HP 08/2012 - 12/2022
2.2 DI-D (GF6W) 2268 CCM 150 HP 08/2012 - 12/2022
2.2 DI-D 4WD (GF6W) 2268 CCM 150 HP 08/2012 - 12/2022
2.0 Hybrid 4WD (GG2W) 1998 CCM 200 HP 01/2014 - 12/2021
2.4 Hybrid 4WD (GG3W) 2360 CCM 208 HP 09/2018 - 12/2022
Plug-in Hybrid (GG2W) 1998 CCM 200 HP 09/2017 - 12/2021
OUTLANDER III Van (GF_W, GG_W)
Description Cylinder Capacity Horse Power Year
Di-D 4WD (GF6W) 2268 CCM 150 HP From 04/2013
PEUGEOT
4007 (VU_, VV_)
Description Cylinder Capacity Horse Power Year
2.2 HDi 2179 CCM 156 HP 02/2007 - 03/2013
2.4 16V 2360 CCM 170 HP 02/2007 - 03/2013

The Brembo 09.A738.11 Brake Disc is a replacement braking component that provides the rotating friction surface acted on by the pads or shoes. Its catalogue specification records internally vented disc construction, 24 mm brake disc thickness, 5 mounting holes, and 69 mm centering diameter. Match the reference, diameter, thickness, mounting pattern and vehicle application before fitting; braking components should be installed and checked by a competent person.

Function : Brake Disc
Brake Disc Type : internally vented
Brake Disc Thickness [mm] : 24
Number of Holes : 5
Height [mm] : 46
Centering Diameter [mm] : 69
Outer Diameter [mm] : 294
Surface : Coated
Minimum thickness [mm] : 22.4
Tightening Torque [Nm] : 100
  • Vendor BREMBO
  • SKU 09.A738.11
  • Barcode 8020584032770
  • CITROËN : 1606375780 1611429880 424959 4249F3
  • MITSUBISHI : 4615A006 4615A113 4615A179 4615A189 46515A189 MR128659 MR205215 MR307376
  • PEUGEOT : 1606375780 1611429880 424958 4249F3
  • APEC : DSK2913
  • BLUE PRINT : ADC44367
  • BLUE PRINT : ADC44392
  • BORG & BECK : BBD4481
  • BOSCH : 0 986 479 372
  • DELPHI : BG4038
  • DELPHI : BG4038C
  • FEBI BILSTEIN : 28440
  • FTE : 9072260
  • HELLA : 8DD 355 111-571
  • MEYLE : 32-15 521 0025
  • MEYLE : 32-15 521 0025/PD
  • MINTEX : MDC1385
  • National : NBD978
  • SKF : VKBD 80127 V2
  • TEXTAR : 92135203
  • TRW : DF6174
  • VALEO : 672931
