BREMBO

Brembo 09.A828.11 Brake Disc

SKU: 09.A828.11

Your selected vehicle

Only 3 left

Low inventory - Hurry! — Orders placed by 17:00 are usually dispatched the same working day

£78.65 inc. VAT

Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery on UK mainland orders. See our delivery information for coverage and current dispatch estimates.

MERCEDES-BENZ

E-CLASS (W211)

Description	Cylinder Capacity	Horse Power	Year
E 240 4-matic (211.080)	2597 CCM	177 HP	03/2003 - 12/2008
E 320 4-matic (211.082)	3199 CCM	224 HP	03/2003 - 12/2008
E 500 4-matic (211.083)	4966 CCM	306 HP	10/2003 - 12/2008

E-CLASS T-Model (S211)

Description	Cylinder Capacity	Horse Power	Year
E 240 T 4-matic (211.280)	2597 CCM	177 HP	07/2003 - 07/2009
E 500 T 4-matic (211.283)	4966 CCM	306 HP	10/2003 - 07/2009

S-CLASS (W220, V220)

Description	Cylinder Capacity	Horse Power	Year
S 430 4-matic (220.083, 220.183)	4266 CCM	279 HP	09/2002 - 08/2005
S 500 4-matic (220.084, 220.184)	4966 CCM	306 HP	09/2002 - 08/2005

The Brembo 09.A828.11 Brake Disc is a replacement braking component that provides the rotating friction surface acted on by the pads or shoes. Its catalogue specification records perforated/vented disc construction, 32 mm brake disc thickness, 5 mounting holes, and 67 mm centering diameter. Match the reference, diameter, thickness, mounting pattern and vehicle application before fitting; braking components should be installed and checked by a competent person.

Function : Brake Disc

Brake Disc Type : perforated/vented

Brake Disc Thickness [mm] : 32

Number of Holes : 5

Supplementary Article/Supplementary Info 2 : with bolts/screws

Height [mm] : 48

Centering Diameter [mm] : 67

Outer Diameter [mm] : 330

Machining : High-carbon

Surface : Coated

Minimum thickness [mm] : 30

Tightening Torque [Nm] : 130

Brembo 09.A828.11 Brake Disc
