BREMBO

Brembo 09.B596.11 Brake Disc

SKU: 09.B596.11

Your selected vehicle

Only 2 left

Low inventory - Hurry! — Orders placed by 17:00 are usually dispatched the same working day

£88.95 inc. VAT

Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery on UK mainland orders. See our delivery information for coverage and current dispatch estimates.

NISSAN

JUKE (F15)

Description	Cylinder Capacity	Horse Power	Year
1.6 DIG-T 4x4	1618 CCM	190 HP	06/2010 - 12/2019
1.6 DIG-T	1618 CCM	190 HP	06/2010 - 12/2019
1.6 DIG-T NISMO 4x4	1618 CCM	200 HP	11/2012 - 12/2019
1.6 DIG-T NISMO	1618 CCM	200 HP	11/2012 - 12/2019

PULSAR Hatchback (C13)

Description	Cylinder Capacity	Horse Power	Year
1.6 DIG-T	1618 CCM	190 HP	From 02/2015

The Brembo 09.B596.11 Brake Disc is a replacement braking component that provides the rotating friction surface acted on by the pads or shoes. Its catalogue specification records internally vented disc construction, 26 mm brake disc thickness, 5 mounting holes, and 68 mm centering diameter. Match the reference, diameter, thickness, mounting pattern and vehicle application before fitting; braking components should be installed and checked by a competent person.

Function : Brake Disc

Brake Disc Type : internally vented

Brake Disc Thickness [mm] : 26

Number of Holes : 5

Height [mm] : 44

Centering Diameter [mm] : 68

Outer Diameter [mm] : 296

Surface : Coated

Minimum thickness [mm] : 24

BLUE PRINT : ADN143155
BORG & BECK : BBD5373
BOSCH : 0 986 479 D15
BOSCH : 0 986 479 R89
DELPHI : BG4283
FEBI BILSTEIN : 170850
HELLA : 8DD 355 125-521
MEYLE : 36-15 521 0071/PD
MINTEX : MDC2765
National : NBD2068
SKF : VKBD 80070 V2
SKF : VKBD 80936 V1
TEXTAR : 92285905
TRW : DF6533
