Brembo 09.D985.11 Brake Disc - 1
Brembo 09.D985.11 Brake Disc - 2
Brembo 09.D985.11 Brake Disc - 1
Brembo 09.D985.11 Brake Disc - 2
BREMBO

Brembo 09.D985.11 Brake Disc

SKU: 09.D985.11
Your selected vehicle
Only 4 left
Low inventory - Hurry! — Orders placed by 17:00 are usually dispatched the same working day
£60.32 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery on UK mainland orders. See our delivery information for coverage and current dispatch estimates.

MERCEDES-BENZ
A-CLASS (W177)
Description Cylinder Capacity Horse Power Year
A 220 4-matic (177.045) 1991 CCM 190 HP 07/2018 - 10/2019
A 220 (177.044) 1991 CCM 190 HP From 07/2018
A 220 d (177.014) 1950 CCM 190 HP From 11/2018
A-CLASS Saloon (V177)
Description Cylinder Capacity Horse Power Year
A 220 4-matic (177.145) 1991 CCM 190 HP From 09/2018
A 220 (177.144) 1991 CCM 190 HP From 01/2019
A 220 d (177.114) 1950 CCM 190 HP From 08/2019
A 220 d 4-matic (177.115) 1950 CCM 190 HP From 10/2019
B-CLASS Sports Tourer (W247)
Description Cylinder Capacity Horse Power Year
B 220 d (247.014) 1950 CCM 190 HP From 12/2018
B 220 4-matic (247.045) 1991 CCM 190 HP From 01/2019
B 220 (247.044) 1991 CCM 190 HP From 04/2019
B 220 d 4-matic (247.015) 1950 CCM 190 HP From 10/2019
CLA (C118)
Description Cylinder Capacity Horse Power Year
CLA 220 4-matic (118.345) 1991 CCM 190 HP From 03/2019
CLA 220 d (118.314) 1950 CCM 190 HP From 04/2019
CLA 220 d 4-matic (118.315) 1950 CCM 190 HP From 07/2020
CLA Shooting Brake (X118)
Description Cylinder Capacity Horse Power Year
CLA 220 d (118.614) 1950 CCM 190 HP From 06/2019
CLA 220 d 4-matic (118.615) 1950 CCM 190 HP From 10/2019
GLA (H247)
Description Cylinder Capacity Horse Power Year
GLA 200 (247.787) 1332 CCM 163 HP From 02/2020
GLA 200 d (247.712) 1950 CCM 150 HP From 02/2020
GLA 200 d 4-matic (247.713) 1950 CCM 150 HP From 02/2020
GLA 180 d (247.710) 1950 CCM 116 HP From 03/2020
GLA 180 (247.784) 1332 CCM 136 HP From 07/2020
GLB (X247)
Description Cylinder Capacity Horse Power Year
GLB 180 d (247.610) 1950 CCM 116 HP From 08/2019
GLB 200 (247.687) 1332 CCM 163 HP From 08/2019
GLB 200 Mild-Hybrid (247.687) 1332 CCM 163 HP From 03/2023

The Brembo 09.D985.11 Brake Disc is a replacement braking component that provides the rotating friction surface acted on by the pads or shoes. Its catalogue specification records internally vented disc construction, 30 mm brake disc thickness, 5 mounting holes, and 67 mm centering diameter. Match the reference, diameter, thickness, mounting pattern and vehicle application before fitting; braking components should be installed and checked by a competent person.

Function : Brake Disc
Brake Disc Type : internally vented
Brake Disc Thickness [mm] : 30
Number of Holes : 5
Supplementary Article/Supplementary Info 2 : with bolts/screws
Height [mm] : 51
Centering Diameter [mm] : 67
Outer Diameter [mm] : 318
Machining : High-carbon
Surface : Coated
Minimum thickness [mm] : 27.4
  • Vendor BREMBO
  • SKU 09.D985.11
  • Barcode 8020584313312
  • MERCEDES-BENZ : 2474210712 247421071207 A2474210712 A247421071207
  • MERCEDES-BENZ (BBDC) : A2474210712
  • APEC : DSK3623
  • BLUE PRINT : ADBP430179
  • BORG & BECK : BBD5640
  • DELPHI : BG5112C
  • FEBI BILSTEIN : 186182
  • HELLA : 8DD 355 133-051
  • MINTEX : MDC2947C
  • TEXTAR : 92316705
