DENSO

Denso DSN1003 Starter Motor

5.0/5 60 AutoMotoPart customer reviews Verified reviews across our products & service
SKU: DSN1003

Check product compatibility

Enter your registration or select your vehicle to check this product fits.

Out of stock
Out of Stock
£142.52 inc. VAT
Pay in 3 interest-free payments with Klarna
Free UK mainland standard delivery 14-day returns

Need help choosing the right part? Call 01472 869 066

TOYOTA
AVENSIS VERSO (_M2_)
Description Cylinder Capacity Horse Power Year
2.0 VVT-i (ACM20_, ACM20R) 1998 CCM 150 HP 08/2001 - 11/2009
2.4 VVT-i (ACM21) 2362 CCM 156 HP 08/2001 - 08/2007
CAMRY Saloon (_V3_)
Description Cylinder Capacity Horse Power Year
2.4 (ACV30, ACV36) 2362 CCM 152 HP 11/2001 - 11/2006
3.0 (MCV30_, MCV30R) 2995 CCM 186 HP 08/2001 - 11/2006
CAMRY Saloon (_V4_)
Description Cylinder Capacity Horse Power Year
2.4 (ACV40) 2362 CCM 158 HP 01/2006 - 09/2011
2.4 (ACV40_, ACV40R) 2362 CCM 167 HP 01/2006 - 09/2011
PREVIA III (_R2_, _R5_)
Description Cylinder Capacity Horse Power Year
2.4 (ACR50_, ACR50R) 2362 CCM 170 HP From 10/2005
RAV 4 III (_A3_)
Description Cylinder Capacity Horse Power Year
2.0 4WD (ACA30_, ACA30R) 1998 CCM 152 HP 02/2006 - 06/2013
2.4 (ACA36, ACA38) 2362 CCM 170 HP 11/2005 - 12/2013
RAV 4 IV (_A4_)
Description Cylinder Capacity Horse Power Year
2.5 4WD (ASA44) 2494 CCM 180 HP 12/2012 - 10/2018
LEXUS
RX (_U3_)
Description Cylinder Capacity Horse Power Year
300 (MCU35_, MCU35R) 2995 CCM 204 HP 05/2003 - 12/2008
350 AWD (GSU35_, GSU35R) 3456 CCM 276 HP 02/2006 - 12/2008
330 AWD (MCU38) 3311 CCM 232 HP 04/2003 - 12/2008
330 (MCU38_, MCU38R) 3311 CCM 232 HP 04/2003 - 01/2006
RX (_L1_)
Description Cylinder Capacity Horse Power Year
350 AWD (GGL15_, GGL15R) 3456 CCM 277 HP 12/2008 - 08/2015

The Denso DSN1003 Starter Motor is a replacement starting or charging-system component that supports electrical power generation, storage or engine cranking in the vehicle. Its catalogue specification records 12 V electrical rating, 1.7 kW rated power, 13 teeth, and automatic Transmission transmission. Match the reference, voltage, output or capacity, terminals, mounting and vehicle application before fitting; isolate the electrical system and follow the manufacturer's coding procedure where required.

Function : Starter
Voltage [V] : 12
Rated Power [kW] : 1.7
Rotation Direction : Anticlockwise rotation
Quality : DENSO
Number of Teeth : 13
Gross Weight [g] : 3,290
Transmission Type : Automatic Transmission
  • Vendor DENSO
  • SKU DSN1003
  • Barcode 8717613054260
  • APEC : ASM1061
  • APEC : ASM1694
  • BLUE PRINT : ADT312102
  • BLUE PRINT : ADT312501
  • BLUE PRINT : ADT312520
  • BORG & BECK : BST2017
  • BORG & BECK : BST2198
  • BORG & BECK : BST2251
  • BORG & BECK : BST2352
  • BOSCH : 1 986 S00 605
  • Carwood Group : BREF032114037
  • Carwood Group : BREF0321986S00605
  • FEBI BILSTEIN : 193423
  • FEBI BILSTEIN : 193927
  • FEBI BILSTEIN : 193931
  • LUCAS : LRS02427
  • NAPA : NSM1061
  • NAPA : NSM1694
  • WAI : 17825N
  • WAI : S131.062
