TRW DF6629 Brake Disc

SKU: DF6629
Your selected vehicle
Only 4 left
Low inventory - Hurry! — Order by 17:00 for same-day dispatch
£103.26 inc. VAT
Pay in 3 interest-free payments with Klarna

Standard delivery

Free standard delivery is available for eligible UK mainland orders. Charges may apply for express services and non-mainland destinations. See our delivery information for details.

OPEL
MOKKA / MOKKA X (J13)
Description Cylinder Capacity Horse Power Year
1.4 (_76) 1364 CCM 140 HP 04/2013 - 12/2019
1.4 4x4 (_76) 1364 CCM 140 HP 06/2012 - 12/2019
1.6 (_76) 1598 CCM 116 HP 06/2012 - 12/2019
1.7 CDTI (_76) 1686 CCM 131 HP 06/2012 - 12/2019
1.7 CDTI 4x4 (_76) 1686 CCM 131 HP 06/2012 - 12/2019
1.4 LPG (_76) 1364 CCM 140 HP 04/2013 - 12/2019
1.6 CDTI (_76) 1598 CCM 136 HP 01/2015 - 12/2019
1.6 CDTI 4x4 (_76) 1598 CCM 136 HP 01/2015 - 12/2019
1.6 CDTI (_76) 1598 CCM 110 HP 06/2015 - 12/2019
1.4 4x4 (_76) 1399 CCM 152 HP 06/2016 - 12/2019
1.4 (_76) 1364 CCM 120 HP 06/2018 - 12/2019
1.6 CDTI 4x4 (_76) 1598 CCM 110 HP 03/2018 - 12/2019
MOKKA X VAN (J13)
Description Cylinder Capacity Horse Power Year
1.6 CDTi (76) 1598 CCM 136 HP From 03/2018
VAUXHALL
MOKKA / MOKKA X (J13)
Description Cylinder Capacity Horse Power Year
1.4 4x4 1364 CCM 140 HP 06/2012 - 12/2019
1.6 1598 CCM 116 HP 06/2012 - 12/2019
1.7 CDTI 1686 CCM 131 HP 06/2012 - 12/2019
1.7 CDTI 4x4 1686 CCM 131 HP 06/2012 - 12/2019
1.4 1364 CCM 140 HP 04/2013 - 12/2019
1.6 CDTi 1598 CCM 136 HP 01/2015 - 12/2019
1.6 CDTi 4x4 1598 CCM 136 HP 01/2015 - 12/2019
1.6 CDTI 1598 CCM 110 HP 06/2015 - 12/2019
1.4 4x4 1399 CCM 152 HP 06/2016 - 12/2019
CHEVROLET
TRAX
Description Cylinder Capacity Horse Power Year
1.6 1598 CCM 116 HP From 12/2012
1.4 AWD 1364 CCM 140 HP From 12/2012
1.7 TD 1686 CCM 131 HP From 12/2012
1.7 TD AWD 1686 CCM 131 HP From 12/2012
1.4 1364 CCM 140 HP From 12/2012
1.4 LPG 1364 CCM 140 HP From 04/2013

The TRW DF6629 Brake Disc is a replacement braking component that provides the rotating friction surface acted on by the pads or shoes. Its catalogue specification records vented disc construction, 5 mounting holes, 300 mm outer diameter, and front axle fitting position. Match the reference, diameter, thickness, mounting pattern and vehicle application before fitting; braking components should be installed and checked by a competent person.

Function : Brake Disc
Brake Disc Type : Vented
Number of Holes : 5
Outer Diameter [mm] : 300
Centering Diameter [mm] : 60
Height [mm] : 45.5
Brake Disc Thickness [mm] : 26
Bore Diameter 2 [mm] : 8.4
SVHC : No information available, please contact the manufacturer!
Fitting Position : Front Axle
  • Vendor TRW
  • SKU DF6629
  • Barcode 3322938260675
  • VAUXHALL : 13502059
  • CHEVROLET : 13502059
  • OPEL : 13502059
  • APEC : DSK3073
  • APEC : SDK6786
  • BLUE PRINT : ADG043208
  • BORG & BECK : BBD5314
  • BOSCH : 0 986 479 666
  • BREMBO : 09.B356.20
  • BREMBO : 09.B356.21
  • BREMBO : 09.B356.2X
  • DELPHI : BG4710C
  • Fahren : FBD6786
  • FEBI BILSTEIN : 43987
  • FTE : 9071228
  • FTE : 9081140
  • HELLA : 8DD 355 118-391
  • MEYLE : 615 521 0017
  • MEYLE : 615 521 0017/PD
  • MINTEX : MDC2394
  • NAPA : NBD5303
  • National : NBD1824
  • SKF : VKBD 80221 V2
  • TEXTAR : 92243303
