Hyundai parts selection starts by separating the model badge from its propulsion and build specification. i10, i20, Tucson, Santa Fe and Ioniq names cover several generations, markets, engines and electrical architectures. A full VIN, production date, body, engine or traction-motor identity, transmission code, driven axle, brake package and fitted assistance systems provide a safer basis than registration year alone.
Use registration lookup to narrow the search, then confirm the vehicle label, technical application and installed component. Imports, late registration, facelift overlap, replacement powertrains and option packages can leave alternatives. Record connector keying, mounting, side, dimensions and original markings. A part from a related Hyundai and Kia platform is not automatically interchangeable: calibration, brackets, spring rate, wiring, software and market approval may differ.
Propulsion type changes the service boundary. Petrol and diesel engines need their exact engine and emissions code; dual-clutch, torque-converter automatic and manual gearboxes have different fluids and commissioning; hybrid and plug-in models combine combustion, high-voltage and regenerative-brake systems. Ioniq-badged vehicles include distinct hybrid, plug-in and battery-electric layouts, while later Ioniq-numbered EVs use different high-voltage platforms.
Match engine oil by complete stated approval and viscosity, coolant by circuit and chemistry, and transmission or reduction-gear lubricant by the exact unit code. Do not infer compatibility from fluid colour or a generic ATF, DCT or EV label. AWD Tucson and Santa Fe variants can have separate transfer/coupling and final-drive service points, while tyre rolling circumference affects driveline control.
High voltage requires trained isolation, a waiting period and proving dead; an off display or silent vehicle is not safe evidence. Inspect battery condition, cooling, wiring, fault data, fluid loss and mechanical wear before replacement. After repair, complete bleeding, adaptation, coding, wheel alignment and camera/radar calibration where specified. Recover rather than drive for deficient brakes or steering, traction-battery damage, fuel leakage, severe overheating, insecure wheels or obstructed visibility. Retain the identified codes and calibration results with the maintenance record for later diagnosis.
Your Current Vehicle
Or
Select Your Vehicle
Shop Parts by Category
Choose a category to view parts for your selected vehicle.
Vehicle Models and Options for HYUNDAI
HYUNDAI Car Part Categories
Only categories with verified fitment products are shown.
HYUNDAI Parts Catalogue Online
Browse catalogue-backed parts by vehicle system.
Hyundai identity is anchored by propulsion architecture
A Tucson model name may describe petrol, diesel, mild-hybrid, full-hybrid or plug-in hardware across different generations. Ioniq can refer to an earlier multi-propulsion family or a later dedicated battery-electric vehicle. Those distinctions change cooling loops, braking, transmissions, charging equipment and diagnostic safety.
Record how the vehicle produces and transmits torque before narrowing individual components. Then add VIN, build point, body, steering side and market.
Five coordinates locate the correct Hyundai system
| Coordinate | Question | Evidence | Parts influenced |
|---|---|---|---|
| Generation/build | Which platform and production split? | Full VIN, label and build date. | Body, electronics, bearings and sensors. |
| Propulsion | Combustion, mild/full hybrid, plug-in or EV? | Powertrain labels and vehicle configuration. | Cooling, charging, brakes and ancillaries. |
| Engine/motor | Which code and rated output? | Build data, marking and diagnostic identity. | Filters, mounts, drives and control parts. |
| Transmission/axles | Manual, automatic, DCT, reduction gear; 2WD/AWD? | Unit code and driveline inspection. | Clutch, shafts, fluids and hubs. |
| Equipment | Which brakes, lamps, sensors and ADAS? | Option record, measurements and scan. | Friction, cameras, radar and modules. |
i10 and i20 still need engine and build resolution
Compact dimensions do not imply simple fitment. Generations can change steering assistance, rear brakes, wheel bearings, emissions sensors and infotainment. Within one body shape, output and transmission options can alter mounts, driveshafts and cooling.
Confirm left or right, front or rear, number of doors, lamp technology and connector. A facelift lamp or mirror may bolt to a similar aperture while using different control wiring.
Tucson and Santa Fe add mass, driven axle and towing variables
Record exact generation, propulsion, two- or all-wheel drive, wheel/brake package, seating and towing equipment. AWD arrangements may use a controlled coupling plus separate final-drive or transfer components. Hybrid rear-drive layouts, where applicable to a particular build, must be identified rather than inferred from an AWD badge.
Springs, dampers and brakes follow axle load and powertrain mass. A heavier-looking replacement or a sports description is not a measured rate or approved capacity.
Ioniq is not one electrical system
| Ioniq context | Energy path | Service emphasis | Selection trap |
|---|---|---|---|
| Hybrid | Engine plus traction motor and small HV battery. | Hybrid transmission, dual cooling and blended brakes. | Choosing conventional-engine parts only. |
| Plug-in hybrid | Engine/motor plus externally charged battery. | Charge inlet, onboard charger and battery cooling. | Assuming full-hybrid electrical hardware matches. |
| Earlier battery EV | Traction battery, inverter, motor and reduction gear. | Charging generation, HV components and coolant. | Ordering by Ioniq name without battery/build. |
| Later Ioniq-numbered EV | Dedicated EV platform and different voltage architecture. | Exact model, battery, charger and thermal system. | Transferring parts from earlier Ioniq EV. |
| Low-voltage network | 12V supply wakes controllers/contactors. | Battery, DC-DC charging and grounds. | Blaming traction battery for every no-READY fault. |
Related Kia architecture does not complete fitment
Hyundai and Kia can share engineering programmes, engine families or transmissions. Individual models still use different body brackets, spring calibration, cooling packages, software, lamp approval and wiring length. Accept a cross-reference only when it explicitly includes the Hyundai application and production range.
Do not build a chain of assumptions through several related vehicles. Confirm the Hyundai original reference or a documented supersession, then check the installed interface.
Software version is part of the component
A matching case and connector cannot prove sensor scaling, security configuration, power rating or control logic. Modules can need coding, immobiliser work, parameter download and calibration after installation.
Engine code governs emissions-compatible servicing
Identify engine family, output, induction, start-stop or hybrid integration and exhaust after-treatment. Diesel particulate filters, petrol particulate filters, EGR and selective reduction equipment create different sensors and oil requirements. Registration date does not reliably establish the fitted emissions stage.
Read stored data before clearing it. A pressure, mixture or temperature fault can be created by leaks, wiring, blocked passages, poor combustion or low supply voltage. Test cause and effect.
Transmission names describe families, not one service
Hyundai applications include manual, torque-converter automatic, dual-clutch and electrified drive units. DCT designs may use different clutch cooling, gear oil, actuator and adaptation procedures. Number of speeds or DCT wording cannot replace the unit code.
Use exact drain, fill and level points; some housings contain separate circuits. Temperature monitoring and diagnostic learning may be required. Do not pour universal fluid or an additive into an uncertain gearbox.
Every fluid belongs to a defined circuit
| Circuit | Identity needed | Compatibility control | Commissioning |
|---|---|---|---|
| Engine oil | Engine, emissions system and operating grade. | Complete stated approval plus viscosity. | Correct filter, fill and level check. |
| Automatic/DCT | Transmission code and chamber. | Specified friction and viscosity characteristics. | Temperature level/basic setting if stated. |
| EV reduction unit | Drive-unit code and model generation. | Dedicated lubricant; no generic ATF assumption. | Correct quantity and leak inspection. |
| Engine/hybrid coolant | Exact loop and coolant specification. | Separate circuits may use distinct fill methods. | Vacuum fill/bleed and pump activation. |
| Brake fluid | Hydraulic control and specified grade. | Keep tools free from mineral contamination. | Diagnostic bleed where required. |
| AWD coupling/final drive | Transfer, coupling and axle code. | Do not combine separate gear/coupling fluids. | Open each correct level point. |
Hybrid and EV thermal systems have active controls
Electric pumps, valves, radiators, chillers and battery heaters can operate in combinations determined by ambient temperature and charging. A cold hose does not prove no flow, and a silent pump may be commanded off. Use live data and model test routines.
Identify each reservoir before topping up. Air locks or mixed coolant can reduce inverter and battery protection. Avoid energising a system after an uncontrolled loss until the leak and bleed path are understood.
High-voltage safety begins before lifting the bonnet
Secure the vehicle and keys, identify automatic wake-up or charging states and follow Hyundai's isolation sequence. Trained technicians use rated PPE and tools, wait for stored energy to discharge and verify zero voltage with a proved test instrument.
Orange cabling is only one visible part of the hazard. Battery cases, inverters, electric compressors and charge equipment remain controlled-access components. Heat, hissing, electrolyte odour, deformation or water ingress calls for emergency isolation and specialist response.
Regenerative braking does not remove friction wear
Hybrid and EV control can blend motor regeneration with hydraulic braking. Light friction use may allow disc corrosion or restricted calliper slides, while emergency and low-speed stops still depend on mechanical brakes. Inspect both faces, pad movement, hoses and parking mechanism.
Brake actuators can pressurise unexpectedly. Apply the service disable, pad replacement and bleed procedure before opening or retracting components.
ADAS fitment changes routine chassis work
Forward cameras, radar and wheel/steering sensors rely on mounting geometry. Windscreen replacement, bumper removal, suspension height, wheel alignment or collision repair can trigger a calibration requirement. Use exact target setup, floor conditions, tyre pressures and diagnostic sequence.
A clear dashboard is not proof of aim. Record successful calibration and confirm no trim, accessory or number-plate position obscures a sensor.
Symptoms should be triaged by energy and control risk
| Symptom | Concern | Immediate choice | Diagnostic direction |
|---|---|---|---|
| Battery heat, smoke or hissing | HV thermal event. | Evacuate and contact emergency specialists. | Do not approach or charge. |
| DCT warning or no drive | Clutch, actuator, fluid or control fault. | Stop and recover if engagement is unreliable. | Codes, voltage, temperature and unit tests. |
| Repeated coolant loss | Engine, inverter or battery-loop leak. | Identify circuit before further use. | Pressure test and controlled bleed. |
| Brake/steering warning | Reduced assistance or mechanical issue. | Stop if control is affected. | Supply, sensors and physical joints. |
| AWD binding/vibration | Tyres, shaft, coupling or axle fault. | Avoid high load and tight turns. | Measure tyres and driveline operation. |
| ADAS unavailable after repair | Alignment, mounting or calibration error. | Do not rely on assistance. | Geometry, codes and calibration record. |
Maintenance and modifications must respect operating envelopes
Use the time, distance and severe-service schedule for the precise powertrain. Include low-use brake inspection, battery cooling inlets, tyre condition, corrosion, charging equipment and separate driveline fluids where relevant.
Wheel, suspension, towing, charging and software changes can affect load, thermal control, sensor aim, insurance and road use. Preserve plated axle weights, wheel load/speed ratings and high-voltage protection; a modified spring or cable does not raise a certified limit.
UK MOT results and engineering correctness answer different questions
The test covers applicable braking, steering, suspension, tyres, lamps, visibility, structure, emissions and warning functions. Hybrids and EVs still require safe mechanical systems, and dangerous battery damage should never wait for a test appointment.
An MOT certificate does not verify gearbox fluid, high-voltage isolation, ADAS aim or component coding. Roadworthiness remains continuous.
Common Hyundai selection mistakes
- Using one model name across several propulsion architectures.
- Assuming Hyundai and Kia platform relatives share every part.
- Identifying an engine by capacity without code and output.
- Selecting a DCT by number of speeds.
- Mixing separate AWD or coolant circuits.
- Choosing fluid by colour or generic category.
- Fitting a module from connector appearance.
- Opening hybrid brakes without the disable procedure.
- Assuming silence establishes high-voltage isolation.
- Skipping ADAS calibration after geometry or sensor disturbance.
Practical Hyundai parts FAQs
Q: What identifies a Hyundai beyond registration?
A: Use VIN/build, body, engine or motor, transmission, driven axle, brakes and fitted assistance systems.
Q: Are Hyundai and Kia parts interchangeable?
A: Only with an explicit application; related architecture can retain different brackets, software, tuning and approvals.
Q: Does Ioniq describe one powertrain?
A: No. It covers distinct hybrid, plug-in and battery-electric vehicles across different platforms.
Q: Can DCT fluid be chosen from gearbox type alone?
A: No. Match the transmission code, internal chamber and exact fluid/service procedure.
Q: Why can an EV have several coolants or loops?
A: Battery, inverter, motor and cabin/charging hardware can use separately controlled thermal circuits.
Q: Is an off vehicle electrically isolated?
A: No. Only trained disconnection, discharge waiting and proving dead establish a safe state.
Q: Can a 12-volt fault stop a Hyundai EV?
A: Yes. Low-voltage power operates controllers and high-voltage contactors, so test it early.
Q: Do regenerative brakes need servicing?
A: Yes. Discs, pads, sliders, fluid and parking mechanisms still corrode and wear.
Q: When is camera or radar calibration needed?
A: Follow Hyundai procedure after relevant glazing, bumper, alignment, suspension or sensor work.
Q: Can one tyre be changed on AWD?
A: Only if construction and rolling circumference remain within the system's stated limits.
Q: Does passing an MOT confirm module coding?
A: No. The test is not a complete software, fitment or calibration verification.
Q: When is recovery the safe choice?
A: Recover for deficient control, HV battery damage, fuel leaks, insecure wheels, severe heat or unsafe visibility.
