LEVC Car Parts
LEVC parts selection starts with the full VIN, build date, model, body and exact electric-drive configuration. TX taxis and VN5 vans use a traction battery and electric propulsion with a petrol range extender, but their mass, duty cycle, passenger or cargo equipment, brakes, suspension, software and body systems are not interchangeable by appearance. Record battery and drive-unit identifiers, range-extender code, charging equipment, axle/brake option and any accessibility or body conversion.
The wheels are driven electrically; the combustion engine is part of the energy-generation system rather than a conventional mechanical driveline to the road. Engine service still requires the specified oil approval, filter, coolant, ignition, fuel and emissions parts. A timing, filter or brake reference from an engine or supplier family does not prove LEVC installation, mounting, connector, calibration or load capacity.
High-voltage work requires trained personnel, controlled keys and charging, the exact isolation and wait procedure and proof that dangerous voltage is absent. The 12-volt disconnect is not sufficient. Underbody impact, battery leakage, abnormal heat, odour, hiss, smoke or an isolation warning calls for quarantine and specialist assessment. Lift only at approved structural points using equipment rated for the vehicle.
Charging and electric-range complaints need evidence from the supply, cable, inlet, onboard charging, state of charge, battery temperature, thermal circuits and low-voltage system. Range-extender operation also depends on fuel quality, engine temperature and emissions control. Do not repeatedly clear warnings or run a forced test without establishing ventilation, heat and state prerequisites.
Urban taxi and delivery duty produces repeated braking, kerb contact, door cycles, idling of auxiliary systems and high annual hours. Match discs, pads, calipers, bearings, tyres, springs and dampers to the axle and duty; inspect inner tyre walls and suspension pickups after impact. Windscreen, steering, suspension or bumper work may require geometry and driver-assistance calibration.
Recover or quarantine for deficient brakes or steering, unsafe tyres, wheel-security concerns, structural or battery impact, fuel leakage, pressure or temperature warnings, charging damage or high-voltage faults. MOT or licensing compliance does not replace accessibility, operator, conversion, load or fleet-release checks.
Your Current Vehicle
Or
Select Your Vehicle
Shop Parts by Category
Choose a category to view parts for your selected vehicle.
LEVC Car Part Categories
Only categories with verified fitment products are shown.
LEVC combines electric drive with an onboard generator
TX and VN5 use electric propulsion, a traction battery, charging equipment and a petrol range extender. The engine supplies energy; it is not serviced as a conventional engine-to-wheel drivetrain.
Record VIN, build, model, battery, motor, range extender, charger, brakes, suspension, wheels and software identity. Include taxi accessibility or van conversion equipment.
Taxi and van configurations carry different duty
A TX may accumulate passenger, ramp, door and steering cycles; a VN5 adds payload, cargo restraint and conversion loads. Similar front-end components can still differ by axle rating or production revision.
Use a VIN-supported reference and verify dimensions, electrical pinning, software, loading and one-use hardware. Preserve labels and scan data before replacement.
Create a hybrid-energy service record
| Evidence | Decision supported | Risk avoided |
|---|---|---|
| VIN/build/software | Vehicle phase and campaigns. | Hardware/calibration mismatch. |
| Battery/motor identifiers | Isolation, parts and lifting. | High-voltage exposure. |
| Range-extender code | Oil, fuel, timing and emissions. | Generic engine selection. |
| Charge-event evidence | Supply versus vehicle fault. | Unnecessary battery replacement. |
| Axle/brake/tyre data | Urban-duty safety parts. | Wrong load capacity. |
| Accessibility/conversion record | Interlocks, mass and release. | Loss of intended function. |
High voltage defines the workshop boundary
Only appropriately trained personnel should secure keys, charging and remote wake-up, use the model isolation and wait time and prove absence of dangerous voltage with suitable test equipment. Record the boundary and isolation owner.
A disconnected 12-volt battery or silent motor does not establish a safe high-voltage state. Prevent unauthorised reconnection throughout work.
Isolation is a process, not one connector
Wear and test the specified protective equipment, identify every relevant source and confirm tester operation before and after proving dead. Restore covers and interlocks only under controlled close-out.
Battery mass changes lifting and collision handling
Use approved vehicle lift pads and equipment rated for total vehicle and battery mass. Underbody panels, coolant pipes and the battery enclosure are not improvised jacking points.
After impact, assess deformation, leakage, temperature, odour, hiss, smoke and isolation status. A suspect pack requires quarantine, monitoring and an emergency plan; do not charge it.
Charging diagnosis separates source and vehicle
Record AC or DC supply, cable, state of charge, temperatures, charge rate and messages. Safely inspect inlet condition, contacts, locking, drainage and heat marks. Compare behaviour on known compliant equipment only when safe.
Supply protection, cable, inlet, onboard charger, DC path, battery management, low-voltage supply or thermal control can each interrupt charging. Repeated reconnection can worsen a hot contact.
Thermal management serves several consumers
Battery, motor, power electronics, cabin and range extender can exchange heat through controlled but distinct circuits. Identify pumps, valves, heat exchangers, coolant specification and bleed or vacuum-fill method.
Do not mix coolants by colour. Electrically driven compressors may require a particular insulating oil; cross-contamination can create a high-voltage leakage fault.
The range extender remains a complete engine system
Use the exact oil viscosity and approval, filter, capacity, timing and ignition data. Inspect intake, exhaust, cooling, fuel and evaporative or emissions controls. Long electric operation does not eliminate time-based engine maintenance.
Short or intermittent engine runs can influence moisture, fuel age and readiness. Oil-pressure warnings, fuel leakage, misfire, heavy smoke or rising temperature require shutdown and measured diagnosis.
Fluids follow the named component and circuit
| System | Required identity | Unsafe shortcut |
|---|---|---|
| Range-extender engine | Engine and formal oil approval. | Generic hybrid oil. |
| Reduction drive | Exact motor/gear unit and method. | Assuming conventional ATF. |
| Battery/motor coolant | Circuit and electrical requirements. | Mixing all cooling loops. |
| Engine coolant | Materials, chemistry and bleed. | Selecting by colour. |
| Brakes | Grade and diagnostic bleed process. | Ignoring a falling level. |
| Air conditioning | Refrigerant, compressor and oil. | Unapproved universal lubricant. |
Regenerative and friction braking work together
Deceleration may blend motor regeneration with hydraulic friction. A driver complaint can involve battery limits, controls, tyres or conventional brakes. Scan data and a physical inspection are both necessary.
Measure discs, pads, calipers, hoses, pipes, parking system and wheel bearings. Regeneration can reduce friction use but does not prevent corrosion or sticking.
Brake service needs controlled electronic modes
Use the specified service mode for electronic parking and diagnostic bleeding. Confirm master-cylinder and ABS operation and never rely on a fault-free scan as proof of hydraulic integrity.
After work, verify pedal reserve, free rotation, measured balance, parking hold and wheel temperature. A long pedal, pull, fluid leak or hot wheel makes the vehicle unfit for duty.
Urban mass accelerates tyre and suspension work
Kerbs, speed humps, repeated turning and payload load joints, dampers, springs, subframes and wheel bearings. Inspect arms, bushes, ball joints, steering links and mounts on both sides after an impact.
Set approved tyre pressures and ride height before geometry. Tighten bonded bushes at the documented position and confirm full-lock clearance.
Tyres must support axle load and electric torque
Match approved size, construction, load/speed rating and pressure. Inspect inner shoulders, sidewalls, date, impact marks and uneven wear. A taxi tyre can retain legal centre tread while geometry damages an edge.
Confirm wheel capacity, offset, centre, fastener seat and brake clearance. Clean mating faces and follow specified torque and recheck practice.
TX accessibility equipment is safety equipment
Inspect ramps, steps, swivel seat or restraint equipment as fitted, wheelchair anchorage, belts, door operation, lighting and interlocks. Use the equipment maker’s ratings and service instructions.
Do not bypass a door or ramp interlock to maintain availability. After trim, body or electrical work, prove operation with a documented functional check.
VN5 body conversions change load and energy routes
Racking, refrigeration, power supplies or other equipment add mass and wiring and may approach battery, brake or coolant paths beneath the floor. Use conversion drawings and preserve clearances and service access.
Read gross and axle plates and account for driver, tools, conversion and cargo. Stronger springs do not change authorised weights.
Low-voltage power controls high-voltage readiness
Load-test the 12-volt battery and measure DC-DC output, grounds and voltage drop. Trackers, meters, radios, door equipment and body conversions can create parasitic load.
A larger battery does not repair a drain. Added circuits need correct fuse, cable capacity, protection and documented isolation.
Driver-assistance calibration follows chassis setup
Windscreen, mirror, bumper, steering, suspension, tyre or alignment work can alter camera or radar reference. Check glass and bracket identity, pressure, ride height and geometry first.
Use the specified static or dynamic procedure and meet its environmental conditions. Clearing a calibration fault is not proof of correct aim.
Electric range is an operating result, not one component
Compare energy use under known route, payload, ambient temperature, cabin heating and tyre pressure. Battery temperature, charging limit, brake drag, geometry, auxiliary load and driving pattern can change range without a failed traction battery.
Use state-of-health data in context and repeat only safe, comparable tests. Do not discharge to an unsafe margin or disable cabin demisting to chase a headline figure. The range extender and fuel system must remain ready even when most journeys are electric.
Emergency and recovery information must travel with the vehicle
Drivers and recovery staff should know the approved tow or transport method, isolation hazards and location of relevant emergency information. Unauthorised wheel-lift towing can rotate a drive unit or compromise the parking system.
After collision, do not assume that an operable vehicle is safe to charge or return to passenger duty. Record impact, warning history, battery assessment and accessibility condition as part of the release.
Use symptoms to make the duty decision
| Finding | Evidence path | Action |
|---|---|---|
| Battery impact/HV warning | Enclosure, isolation and temperature. | Quarantine. |
| Hot charge inlet | Supply, cable, contacts and locking. | Stop charging. |
| Long or pulling brake | Blend, hydraulics, friction and tyres. | Withdraw from service. |
| Range-extender fuel leak | Tank, lines, pressure and engine. | Switch off. |
| Accessibility interlock fault | Mechanism, sensor and control. | Do not bypass. |
| Tyre impact/steering shift | Wheel, suspension and geometry. | Inspect before duty. |
Return to duty through a written release
- Confirm VIN, software and energy-system identity.
- Record duty, faults, impacts and conversion.
- Control high voltage, charging, fuel and lifting.
- Use circuit-specific fluids and rated parts.
- Restore shields, interlocks, seals and drainage.
- Measure brakes, tyres, suspension and wheels.
- Prove charging, range extender and thermal control.
- Calibrate assistance systems where required.
- Test progressively under representative duty.
- Record driver checks and follow-up.
MOT is only one part of LEVC compliance
The applicable UK test, taxi licensing or commercial requirements depend on vehicle and use. A pass does not confirm accessibility equipment, payload, charging installation, conversion or fleet-release condition.
Known defects remain the operator’s responsibility. Declare body, suspension, wheel, powertrain and software changes to the insurer and relevant licensing authority.
Practical LEVC parts FAQs
Q: Does the range extender drive the wheels mechanically?
A: No. Propulsion is electric.
Q: Are TX and VN5 parts automatically identical?
A: No. Verify VIN, axle and body specification.
Q: Is a silent LEVC de-energised?
A: No. High-voltage isolation must be proven.
Q: Does disconnecting 12 volts make HV work safe?
A: No. Follow the complete isolation procedure.
Q: Can a battery enclosure support a jack?
A: No. Use approved structural points.
Q: May an impacted pack be charged for diagnosis?
A: No. Quarantine it for assessment.
Q: Is a charging fault always inside the battery?
A: No. Supply, inlet, charger and thermal causes exist.
Q: Does regeneration eliminate brake servicing?
A: No. Friction brakes can corrode or seize.
Q: Do stronger springs increase VN5 payload?
A: No. Plated limits remain.
Q: May a ramp or door interlock be bypassed?
A: No. Restore its designed function.
Q: Is alignment enough after windscreen work?
A: No. ADAS calibration may be required.
Q: When should an LEVC be quarantined?
A: For battery impact, heat, leakage or HV warnings.
Q: Does MOT cover taxi accessibility checks?
A: No. Licensing and equipment duties are separate.
