Aixam parts need to match the exact lightweight vehicle, not simply a familiar model name. Record the VIN or chassis number, registration and build dates, body version, engine or electric drive identity, transmission or reduction-gear details, axle and brake specification. Confirm labels, dimensions, connectors and the fitted component because imported vehicles, production changes and previous repairs can defeat a registration-only lookup.
Diesel variants commonly combine a compact engine with a dry belt continuously variable transmission, primary and secondary variators and a forward/reverse gearbox. Belt width, length and profile, variator faces, springing, weights and centre spacing work as a system. Keep oil and grease away from the belt surfaces, repair any source of contamination and follow the correct guarded inspection and adjustment procedure.
Electric variants require a different selection path: traction-battery chemistry and voltage, motor, inverter, charger, DC-DC converter, reduction gear and cooling arrangement must agree. Orange cables and traction components can retain dangerous voltage after shutdown. Isolation, proving dead and battery work belong with trained personnel using vehicle-specific information; a 12-volt warning does not make the high-voltage side safe.
Engine oil, coolant, gearbox oil and brake fluid must meet the exact specification and quantity. Electric reduction drives and thermal circuits also need their stated fluids. Never infer a lubricant from colour or use a generic additive to mask noise, leakage or poor engagement. Check level by the documented vehicle attitude and temperature method.
Brakes, steering, suspension and tyres are safety-critical despite the vehicle's low mass. Match disc or drum dimensions, caliper or wheel-cylinder type, hose ends, bearing and hub details. Confirm spring and damper length, bush dimensions and steering joints. Use the correct wheel fasteners, tyre size, load and speed ratings and pressures, then verify free rotation, clearance and alignment.
Body panels may be lightweight moulded material, but latches, hinges, glazing, lighting mounts and the supporting chassis still require correct fit and secure fasteners. Diagnose warning lamps, poor starting, drive-belt noise, weak braking, steering play, overheating or charging faults before replacing parts. Check the V5C classification and current UK licence, testing and road-use requirements for the individual vehicle. Do not drive with braking, steering, tyre, chassis, uncontrolled transmission or high-voltage faults; arrange competent repair or recovery.
Your Current Vehicle
Or
Select Your Vehicle
Shop Parts by Category
Choose a category to view parts for your selected vehicle.
Vehicle Models and Options for AIXAM
AIXAM Car Part Categories
Only categories with verified fitment products are shown.
Vehicle class changes the servicing context
An Aixam is a lightweight quadricycle or microcar application rather than a conventional small car scaled down in every detail. Its powertrain, hubs, brakes, suspension and body construction are selected around low mass and a defined vehicle category. Generic car dimensions or workshop habits can therefore be unsafe.
Start by reading the individual V5C classification and vehicle identification. Registration date, body style and model wording are useful, but they do not establish every production split, imported specification or later conversion.
Build an evidence chain before selecting parts
| Evidence | What it can establish | Limit to remember |
|---|---|---|
| VIN or chassis number | Vehicle family, production identity and build references. | Does not prove that every fitted component remains original. |
| Registration/V5C | Recorded identity, fuel type and vehicle classification. | Imported or amended records may need physical confirmation. |
| Engine or motor label | Installed power-unit family and serial evidence. | Ancillaries and control revisions can still vary. |
| CVT or reduction-drive markings | Transmission family and service reference. | Belt, variator or gearing must also match the assembly. |
| Brake and hub measurement | Actual disc, drum, caliper, cylinder and bearing interfaces. | Dimensions alone do not prove material or load capability. |
| Connector and part number | Electrical or physical revision of the installed part. | A matching plug does not prove voltage or calibration. |
Diesel and electric architectures diverge early
A diesel vehicle can use a compact compression-ignition engine, belt CVT and separate forward/reverse gearbox. An electric version instead combines a traction battery, power electronics, motor and reduction drive. Service kits cannot be transferred between those architectures simply because the body shell looks alike.
Within either type, production revisions can change mountings, controllers, cooling pipes, shafts and instrument communication. Read labels before disconnecting anything and preserve photographs of cable or hose routing.
Powertrain selection should be system based
| System | Details to verify | Consequence of a mismatch |
|---|---|---|
| Diesel engine | Full model, serial range, fuel and governor equipment. | Poor fit, incorrect speed control or unreliable starting. |
| Primary variator | Shaft, taper, weights, ramps, spring and faces. | Wrong engagement speed or belt travel. |
| Secondary variator | Hub, spring, helix and alignment. | Belt slip, overspeed or uneven wear. |
| CVT belt | Profile, length, width and approved wear limit. | Loss of drive, poor ratio range or breakage. |
| Forward/reverse gearbox | Casing, selector, ratio, shafts and oil specification. | Selection fault, noise or damaged gears. |
| Electric drive | Battery voltage, motor, inverter, charger and reduction unit. | Electrical hazard or incompatible control. |
The CVT is a dry friction system
Primary and secondary variators change their effective pulley diameters as speed and load change. The belt transfers drive by wedging against clean faces; it is not a lubricated chain. Oil, grease or solvent residue can create slip, heat and rapid surface damage.
Measure belt width and inspect for glazing, cracking, missing material and uneven side wear against the exact limit. Do not judge by apparent tightness alone. A new belt cannot correct worn pulley faces, loose mountings, misalignment or a sticking variator.
Stored spring force requires controlled tooling
Variator springs and retainers can release energy suddenly. Use the specified holding and compression tools, keep the assembly guarded and never run an exposed transmission near hands, clothing or observers. Observe nut replacement and torque instructions rather than using an impact tool as the final tightening method.
Engagement behaviour is diagnostic evidence
Drive creep, delayed take-up, shudder or failure to reach ratio can arise from belt wear, contaminated faces, incorrect idle speed, worn engine mounts, variator sticking or gearbox drag. Record engine speed and vehicle behaviour before replacing one visible component.
Do not alter governor, variator weights or travel stops to chase road speed. Such changes can over-speed the engine or transmission and may move the vehicle outside its classified specification, insurance position or safe braking capability.
The forward/reverse gearbox needs its own service data
The compact gearbox is separate from the dry belt area. Identify its fill and level points, oil approval and quantity. Overfilling can aerate oil or create leaks; underfilling can damage bearings and gears. A red or amber fluid colour is not a specification.
Difficulty selecting direction may involve cable adjustment, lever condition, clutch drag within the CVT behaviour, mounting movement or internal wear. Keep the brake applied and follow the stated stationary selection method during tests.
Diesel servicing must respect a compact installation
Use the exact engine-oil viscosity, performance approval, filter and capacity. Small sumps offer little margin for overfill or neglect. Check the level on the stated surface and after the specified settling period, then investigate fuel dilution, repeated top-ups or metallic debris.
Starting faults can involve battery state, glow equipment, fuel supply, compression, stop control or wiring. Avoid prolonged cranking that overheats cables and the starter. Fuel injection, engine governing and timing work should follow the engine manufacturer's data and cleanliness standard.
Cooling faults become serious quickly
A small coolant capacity can lose reserve rapidly. Inspect radiator surfaces, cap, thermostat, pump, fan, hoses and heater circuit, then use the named coolant technology and mix. Different coolants that share a colour may have incompatible chemistry.
Stop for overheating, steam or sudden coolant loss. Never open a hot cap. Pressure-test a cold system only to its stated limit, repair the cause and bleed trapped air using the vehicle's sequence.
Electric variants add high-voltage controls
Traction batteries, inverters, motors and chargers can remain dangerous when the ignition display appears off. Orange cabling should be treated as high voltage. Isolation, waiting time, proving dead, insulated equipment and battery lifting procedures require trained personnel and current model information.
Battery chemistry, module arrangement and control software are part of compatibility. Do not substitute cells, chargers or contactors by physical resemblance. A damaged traction battery, unusual heat, odour, impact or water ingress calls for isolation of the area and specialist guidance rather than routine dismantling.
The 12-volt system still controls critical states
A weak auxiliary battery or poor earth can prevent contactors closing and generate drive, charging or display faults. Test loaded voltage, fuses, connectors and earth paths before condemning high-voltage hardware, but never assume a 12-volt diagnosis has made the traction system safe.
Brakes remain safety-critical at low mass
Disc diameter, thickness, height and hub interface must match the installed caliper. Drum systems require the correct internal diameter, shoe contour, cylinder bore and adjuster layout. Hoses need exact ends and enough movement without twisting or contacting the tyre.
Use the specified brake-fluid chemistry from a sealed container. Diagnose a low pedal, pull, binding or fluid loss before road use. After hydraulic work, bleed by the stated sequence, verify free wheel rotation and perform a controlled balance test.
Suspension and steering rely on accurate small dimensions
Short arms, light hubs and compact joints do not make looseness acceptable. Confirm ball-joint taper, track-rod thread, bush diameter, spring free length, damper stroke and mounting width. A few millimetres can alter travel or geometry materially.
Support the chassis at approved points and never work beneath an unsupported vehicle. Tighten bonded bushes at the defined ride position, torque wheel fasteners correctly and align steering after geometry is disturbed.
Tyres are part of stability and gearing
Match size, construction, load index, speed rating and approved axle pairing. Maintain stated cold pressures and examine date, sidewalls, beads and inner tread. Incorrect circumference can change indicated speed, CVT operating range and braking behaviour.
Wheel diameter alone does not prove fit. Confirm width, offset, centre bore, fastener seat and clearance to calipers, suspension and body throughout steering and suspension movement.
Body panels and chassis have different roles
Lightweight moulded panels may crack around over-tightened fittings, while hinges, door latches, belt anchors, glazing retention and lighting mounts must remain secure. Use compatible repair materials and fasteners; a cosmetic patch must not hide damage to the supporting frame.
After an impact, inspect chassis alignment, suspension pick-up points, steering, brake pipes and battery area, not only the outer panel. Poor door closure or new tyre wear can be evidence of underlying movement.
Symptoms should direct tests, not guesses
| Symptom | Checks to prioritise | Urgency |
|---|---|---|
| CVT squeal or slip | Belt condition, face contamination, alignment and mounts. | Stop if drive is unpredictable or the belt is damaged. |
| No diesel start | Battery, glow, fuel, stop control and compression. | Avoid repeated overheating of starter wiring. |
| Electric no-ready state | 12-volt supply, interlocks and diagnostic data. | Do not open high-voltage assemblies untrained. |
| Brake pull/low pedal | Leaks, friction condition, adjustment and hydraulics. | Do not drive until corrected. |
| Steering play | Joints, rack mounts, hubs and chassis points. | Unsafe movement requires recovery. |
| Overheating | Level, leaks, circulation, fan and radiator airflow. | Stop, cool fully and diagnose. |
A measured service sequence reduces repeat faults
- Record VIN, V5C classification, build and powertrain type.
- Read engine, motor, transmission, brake and electrical labels.
- Photograph routing and measure the installed interfaces.
- Diagnose symptoms before ordering or dismantling.
- Isolate fuel, spring, brake and electrical hazards correctly.
- Use exact fluids, belts, seals and replacement fasteners.
- Keep CVT friction faces clean and high-voltage areas controlled.
- Restore guards, clips, ducts, earths and body retainers.
- Adjust, bleed, align or calibrate by the model procedure.
- Test progressively, then reinspect levels, heat and security.
UK road use depends on the individual classification
Licence entitlement, testing requirements and operating rules can depend on the recorded category, vehicle age and current UK law. Check the V5C and current official GOV.UK guidance rather than relying on assumptions about all microcars. Imported, modified or converted vehicles need particular care.
A valid test status is not proof that the CVT, fluids or service parts are correct. Brakes, steering, tyres, lamps, glazing, seat belts, structure, emissions equipment and warnings must remain roadworthy between tests. Resolve any control or electrical safety fault before use.
Practical Aixam parts FAQs
Q: Is registration lookup enough to choose a part?
A: No. Confirm the VIN, build, labels and fitted dimensions.
Q: Can every Aixam use the same CVT belt?
A: No. Match profile, length, width and transmission application.
Q: Should a CVT belt be lubricated?
A: No. It operates on clean, dry variator faces.
Q: Does belt slip prove the belt alone is faulty?
A: No. Check contamination, faces, alignment, mounts and variators.
Q: Can variator weights be changed for more speed?
A: Do not alter classified performance or exceed system limits.
Q: Is the gearbox oil shared with the CVT?
A: No. The dry belt and geared casing are serviced differently.
Q: Can engine oil be chosen by viscosity alone?
A: No. Use the exact approval, grade and quantity.
Q: Is an electric Aixam safe when switched off?
A: High voltage may remain; use the formal isolation procedure.
Q: Can a weak 12-volt battery stop electric drive?
A: Yes. It can prevent control systems entering ready state.
Q: Are small brakes less safety-critical?
A: No. Any hydraulic, friction or balance fault is urgent.
Q: Can ordinary car wheels be fitted by diameter?
A: No. Width, offset, seat, load and clearance must match.
Q: Are cracked outer panels only cosmetic?
A: Not always. Inspect latches, mounts and supporting structure.
Q: Do all Aixam vehicles follow one UK licence rule?
A: Check the individual classification and current official requirements.
Q: What confirms a successful repair?
A: Correct fit, stable operation and no leaks, warnings or unsafe movement.
